7
Model
Indoor CS-E9PB4EA
Outdoor CU-E9PB4EA
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8)
Standard length m (ft) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 20 (65.6)
I/D & O/D Height different m (ft) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Length for Additional Gas m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 30
Length mm 193
Indoor Heat
Exchanger
Fin Material Aluminium (Pre Coat)
Fin Type Slit Fin
Row × Stage × FPI 2 × 10 × 18
Size (W × H × L) mm 1330:1270 × 210 × 25.4
Outdoor
Heat
Exchanger
Fin Material Aluminium
Fin Type Corrugated Fin
Row × Stage × FPI 2 × 28 × 17
Size (W × H × L) mm 36.4 × 588 × 606.6
Air Filter
Material –
Type –
Power Supply Outdoor
Power Supply Cord A Nil
Thermostat Electronic Contol
Protection Device Electronic Contol
Dry Bulb Wet Bulb
Indoor
Operation
Range
Cooling
Maximum °C 32 23
Minimum °C 16 11
Heating
Maximum °C 30 –
Minimum °C 16 –
Outdoor
Operation
Range
Cooling
Maximum °C 43 26
Minimum °C -10 –
Heating
Maximum °C 24 18
Minimum °C -10 –
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C DRY BULB (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb)
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb)
Ú3 Heating low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor 2/1°C
Ú4 Heating extreme low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor -7/-8°C
5 Standby power consumption ≤0.7W (when switched OFF by remote control, except under self protection control).
6 Specifications are subjected to change without prior notice for further improvement.
