Panasonic CS-F43DTE5 Service Manual

130
15 Replacement Part List (Indoor Unit)
15.1. CS-F24DTE5 CS-F28DTE5
NO. PART DESCRIPTION QTY. CS-F24DTE5 CS-F28DTE5
1 CABINET TOP PLATE 1 CWE001015 ←
2 CABINET FRONT PLATE 1 CWG07K1009 ←
3 CABINET SIDE PLATE (L) 1 CWD63K1001 ←
4 VANE SUPPORTER (L) 1 CWG071146 ←
5 CATCHER 1 CWH601005 ←
6 CABINET SIDE PLATE (R) 1 CWD63K1002 ←
7 VANE SUPPORTER (R) 1 CWG071147 ←
8 BLOWER WHEEL BASE ASS’Y 1 CWD90K1007 ←
9 BRACKET FAN MOTOR ASS’Y 1 CWD54K1006 ←
10 BEARING 1 CWH64C1001 ←
11 BEARING COVER 1 CWD911196 ←
12 FAN SHAFT 1 CWH631030 ←
13 COUPLING SHAFT COMPLETE 1 CWH08C1001 ←
14 SCREW-COUPLING SHAFT COMPLETE 2 CWH55424 ←
15 AIR GUIDER B. WHEEL (TOP) 4 CWD321026 ←
16 AIR GUIDER B. WHEEL (BOTTOM) 4 CWD321027 ←
17 BLOWER WHEEL 1 CWH011004 ←
18 BLOWER WHEEL 3 CWH011009 ←
19 FAN MOTOR 1 CWA921053 ←
20 FAN MOTOR SUPPORTER 2 CWD93C1027 ←
21 SIDE FILTER SEAL 1 CWD911158 ←
22 SEPARATOR 1 CWD911106 ←
23 EVAPORATOR COMPLETE 1 CWB30C1559 ←
24 TUBE ASS’Y (CAPIL. TUBE-EVA) 1 CWT07K1246 ←
25 FLARE NUT (3/8”) 1 CWT25087 ←
26 FLARE NUT (5/8”) 1 CWT251016 ←
27 HEATPROOF TUBE [LIQUID] 1 CWG021024 ←
28 HEATPROOF TUBE [GAS] 1 CWG021022 ←
29 WATERPROOF COVER 1 CWG251006 ←
30 SENSOR-EVAPORATOR 1 CWA50C2232 ←
31 HOLDER SENSOR 1 CWH32137 ←
32 VANE COMPLETE 1 CWE24C1016 ←
33 VANE SIDE HOLDER 2 CWH511027 ←
34 FULCRUM 2 CWH621008A ←
35 VERTICAL VANE HOLDER (MANUAL) 3 CWD911107 ←
36 VERTICAL VANE (HORIZ.AIR FLOW) 12 CWE241051 ←
37 CONNECTING BAR 6 CWE261019 ←
38 AIR SWING MOTOR COMPLETE 1 CWA98C1004 ←
39 CONTROL BOARD ASS’Y 1 CWH10K1050 ←
40 TERMINAL BOARD 1 CWA281031 ←
41 CAPACITOR-FAN MOTOR (MF/V) 1 DS451135BPQB DS451205BPQC
42 ELECTRONIC CONTROLLER-MAIN 1 CWA73C1695 CWA73C1696
43 LOCKING GUARD SPACER 6 CWH541026 ←
44 CONTROL BOARD COVER-COMPLETE 1 CWH13C1106 ←
45 TRANSFORMER 1 CWA40C1031 ←
46 SENSOR COMPLETE 2 CWA50C2233 ←
48 CABLE CLIP (CORD CLAMPER) 1 CWH88133 ←
49 WIRE SADDLE 2 CWH881019 ←
50 DRAIN PAN ASS’Y 1 CWH40K1014 ←
51 DRAIN PLUG 1 CWB821002 ←
52 CABINET BOTTOM PLATE 1 CWE051001A ←
53 CURVED WIRE 1 CWH751002 ←
54 RAY RECEIVER HOLDER 1 CWD911428 ←
55 INTAKE GRILLE (LARGE) 2 CWE221029 ←
56 GRILLE SLIDE HOOK 4 CWH891001 ←
57 AIR FILTER (MAIN) 2 CWD001169 ←
58 AIR FILTER (SIDE) 1 CWD001041 ←
59 BRACKET HANGER (R) 1 CWD601014 ←
60 BRACKET HANGER (L) 1 CWD601015 ←
61 CABINET SIDE COVER (R) 1 CWE041022 ←
62 CABINET SIDE COVER (L) 1 CWE041023 ←
