19 Replacement Part List (Outdoor Unit)
19.1. CU-J24DBE5 CU-J24DBE8 CU-J28DBE5 CU-J28DBE8
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
NO. PART DESCRIPTION QTY. CU-J24DBE5 CU-J28DBE5 CU-J28DBE5 CU-J28DBE8
1 BASE PAN ASS’Y 1 CWD52K1102 ←←←
2 COMPRESSOR 1 5JS315DAM21 5JS315PAA21 5JS330DAF21 5JS330PBA21
3 ANTI-VIBRATION BUSHING 3 CWH50055 ←←←
4 NUT FOR COMP. MOUNT. 3 CWH561049 ←←←
5 PACKING 3 CWB811017 ←←←
6 CRANKCASE HEATER 1 CWA341017 ←←←
7 CONDENSER COMPLETE 1 CWB32C1718 ←←←
9 PIPE HOLDER RUBBER 1 CWG251016 ←←←
13 HEATING PRESSURE SWITCH 1 CWA101013 ←←←
14 TUBE ASS’Y(EXP.VALVE AND
STRAINER)
1 CWT023961 ←←←
15 3-WAYS VALVE(LIQUID) 1 CWB011252 ←←←
16 3-WAYS VALVE(GAS) 1 CWB011251 ←←←
17 TUBE RECEIVER 1 CWB141031 ←←←
18 STRAINER 2 CWB111032 ←←←
19 PIPE HOLDER RUBBER 1 CWG251016 ←←←
20 HOLDER-SERVICE VALVE 1 CWD911425 ←←←
21 SOUND-PROOF BOARD 1 CWH151078 ←←←
23 SOUND PROOF MATERIAL 1 CWG302338 ←←←
25 V-COIL COMPLETE 1 CWA43C2128J ←←←
26 PIPING SENSOR 1 CWA50C2292 ←←←
27 PIPING SENSOR 1 CWA50C2293 ←←←
28 SPRING FOR SENSOR 2 CWH711010 ←←←
29 CABINET REAR PLATE COMPLETE 1 CWE02C1029 ←←←
30 CONTROL BOARD ASS’Y 1 CWH10K1063 CWH10K1064 CWH10K1063 CWH10K1064
31 TERMINAL BOARD ASS’Y 1 CWA28K1085J CWA28K1109 CWA28K1085J CWA28K1109
32 TERMINAL BOARD ASS’Y 1 CWA28K1076J ←←←
33 CAPACITOR-FM (2.5mF/460V)(3.0mF/
460V)
1 DS461255QP-A ← DS461305QP-A ←
34 CAPACITOR-COMP (45mF/370V) (50mF/
370V)
1 DS371456CPNA - DS371506CPNA -
35 HOLDER CAPACITOR 1 CWH30060 - CWH30060 -
36 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1892 CWA73C1893 CWA73C1894 CWA73C1895
37 MAGNETIC RELAY 1 K6C2A9A00001 K6C4A8A00003 K6C2A9A00001 -
38 TRANSFORMER 1 CWA401060 ←←←
39 TERMINAL COVER 1 CWH171012 ←←←
40 NUT FOR TERMINAL COVER 1 CWH7080300J ←←←
41 BRACKET FAN MOTOR ASS’Y 1 CWD54K1025 ←←←
42 SCREW-BRACKET FAN MOTOR 2 CWH551040J ←←←
43 FAN MOTOR AC 70W SINGLE 1 CWA951366 ←←←
44 SCREW-BRACKET FAN MOTOR 4 CWH551040J ←←←
45 PROPELLER FAN 1 CWH001019 ←←←
46 NUT for PROPELLER FAN 1 CWH561038J ←←←
47 CABINET TOP PLATE COMPLETE 1 CWE03C1039 ←←←
48 PIPE COVER (FRONT) 1 CWD601074A ←←←
49 PIPE COVER (BACK) 1 CWD601081A ←←←
50 CABINET FRONT PLATE 1 CWE061118A ←←←
51 DISCHARGE GRILLE 1 CWE201073 ←←←
52 CABINET SIDE PLATE ASS’Y 1 CWE04K1019A ←←←
53 WIRE NET 1 CWD041063A ←←←
54 CABINET FRONT PLATE COMPLETE 1 CWE06C1147 ←←←
55 HANDLE 3 CWE161008 ←←←
56 LEADWIRE-COMPRESSOR 1 CWA67C5994 CWA67C5909 CWA67C5994 CWA67C5909
57 WIRINF COVER AND BAND 1 CWH82C1105 ←←←
58 INSTALLATION INSTRUCTION 1 CWF612864 ←←←
60 ELECTRO MAGNETIC SWITCH 1 - - - K6C4E8A00003
