Panasonic CS-PC9KKV

22
Indoor Unit
Outdoor Unit
Model
CS-PC9KKV
CU-PC9KKV
CS-PC12KKV
CU-PC12KKV
COOL
COOL
Single, 220V,
60Hz
Single, 230V,
60Hz
Single, 220V,
60Hz
Single, 230V,
60Hz
Power/Current
[W] 830 840
1210 1220
[A] 4.20 4.20
5.60 5.60
Refrigerant
[kg]
R22*
0.480
R22*
0.710
Cooling Capacity
[kW] 2.500
3.500
Noise Level
JIS C 9612 [<70 dB(A)]
[dB(A)]
36
39
Conditions 1m Distance
Max. cooling
49
49
Air Circulation
[m
3
/min.] 10.5
11.5
Product Weight
[kg]
9.0
9.0
24.0
26.5
Dimensions (L × W × H)
[mm]
848 × 204 × 290
848 × 204 × 290
650 × 230 × 530
650 × 230 × 530
Test conditions
1.
Temperature (°C)
Indoor Outdoor
*DBT *WBT *DBT *WBT
COOLING 27 19 35 24
2. Standard piping length: 5 m (Includes Indoor Unit piping length).
3. Air lters are attached.
PRODUCT SPECIFICATION
*60
g
for air purging is not included.
F567253_EN_CS4.indd 22 2009-12-4 15:09:44
