4.2 Outdoor Unit
4.2.1 CU-S9TKV
4.2.2 CU-S12TKV
474
736
88
(650)18
88
230 5183
79
134
261 293
511
149
88
<Top View>
<Front View>
<Side View>
<Side View>
Anchor Bolt Pitch
261 × 474
Space necessary for
installation
100 mm
100 mm
1000 mm
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
Unit : mm
780
104.9
67.6
570
60.5
34.3155.2
320
85.5
61.669.5
(18)
542
28939
(104.7)
22
Space necessary for
installation
<Side View><Side View> <Front View>
<Top View>
Anchor Bolt Pitch
320 x 570
100 cm
10 cm
10 cm
Unit : mm
2-way valve at
Liquid side
(High Pressure)
3-way valve at
Gas side
(Low Pressure)
R32
REFRIGERANT
