Page #24 background imageLoading...
Page #24 background image
24
6.5 CS-S28TKV CU-S28TKV
1
L
N
3
2
FUSE3
FUSE2
FUSE1
DB3
DB1
DB2
Q1
U
P
N
V
W
SC
SSR1
PTC2
PTC1
RY-AC
RY-C
RY-PWR2
RY-HL
NTC
TH2
NTC
TH1
NOISE FILTER
M
1~
MS
3~
CR4
CR5
CT400 REACTOR
TEMP.FUSE
U
FUSE301
SC
(INDOOR UNIT)
SINGLE PHASE
OUTDOOR
POWER SUPPLY
(OUTDOOR UNIT)
M
