Panasonic CS-S12TKV

154
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-S9TKV CS-S12TKV REMARK
1 CHASSIS COMPLETE 1 CWD50C1605 ←
2 FAN MOTOR 1 L6CBYYYL0037 ← O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1076 ←
4 BEARING ASSY 1 CWH64K1006 ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ←
6 GENERATOR COMPLETE 1 ACXH94C00300 ←
7 EVAPORATOR 1 ACXB30C03490 ACXB30C09980
8 FLARE NUT (LIQUID) 1 CWT251048 ←
9 FLARE NUT (GAS) 1 CWT251049 CWT251032
10 CONTROL BOARD CASING 1 ACXH10-00200 ←
11 PARTICULAR PIECE - TERMINAL 1 CWD933138 ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2692 CWA28C2691 O
13 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C21700 ACXA73C21710 O
14 ELECTRONIC CONTROLLER - HVU 1 N0GE1F000007 ← O
15 ELECTRONIC CONTROLLER - INDICATOR 1 ACXA73-07310 ← O
15A ELECTRONIC CONTROLLER - RECEIVER 1 ACXA73-07230 ← O
16 INDICATOR HOLDER 1 ACXD93-00930 ←
16A INDICATOR HOLDER 1 ACXD93-00700 ←
17 SENSOR COMPLETE 1 CWA50C2122 ← O
18 SENSOR COMPLETE (ECO) 1 CWA50C3265 ← O
19 ELECTRONIC CONTROLLER (ECO SENSOR) 1 CWA745791 ← O
20 ELECTRONIC CONTROLLER (ECO SENSOR) 1 CWA746206 ← O
21 ELECTRONIC CONTROLLER (COMPARATOR) 1 CWA747891 ← O
22 LEAD WIRE - PCB ECO 1 CWA68C1926 ←
23 CONTROL BOARD CASING FOR PCB ECO 1 CWD933929 ←
24 CONTROL BOARD CASING FOR PCB ECO 1 CWD933930 ←
25 CLIP FOR SENSOR 1 CWH711019 ←
26 DISCHARGE GRILLE COMPLETE 1 ACXE20C01030 ←
27 BACK COVER CHASSIS 1 CWD933233A ←
28 FULCRUM 1 ACXH62-00040 ←
29 VERTICAL VANE 8 CWE241457 ←
30 CONNECTING BAR 1 CWE261314 ←
31 AIR SWING MOTOR 1 ACXA98K00020 ← O
32 AIR SWING MOTOR 1 CWA981241 ← O
33 AIR SWING MOTOR 1 CWA981299 ← O
34 CAP - DRAIN TRAY 1 CWH521259 ←
35 HORIZONTAL VANE COMPLETE 1 ACXE24C00390 ←
36 HORIZONTAL VANE COMPLETE 1 CWE24C1514 ←
37 CONTROL BOARD TOP COVER 1 ACXH13-00190 ←
38 CONTROL BOARD FRONT COVER CO. 1 ACXH13C00150 ←
39 REMOTE CONTROL COMPLETE 1 ACXA75C03550 ← O
40 FRONT GRILLE COMPLETE 1 ACXE10C03380 ← O
41 INTAKE GRILLE COMPLETE 1 ACXE22K00120 ←
42 GRILLE DOOR COMPLETE 1 CWE14C1091 ←
43 AIR FILTER 2 CWD001279 ← O
44 CAP - FRONT GRILLE 2 ACXH52-00020A ←
45 SCREW - FRONT GRILLE 3 XTT4+16CFJ ←
