Panasonic CS-S12TKV

157
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-S18TKV CS-S24TKV CS-S28TKV REMARK
1 CHASSIS COMPLETE 1 ACXD50C00310 ← ←
2 FAN MOTOR 1 L6CBYYYL0177 L6CBYYYL0193 ← O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1136 ← ←
4 BEARING ASSY 1 CWH64K1010 ← ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ← ←
6 GENERATOR COMPLETE 1 ACXH94C00300 ← ←
7 EVAPORATOR 1 ACXB30C03240 ACXB30C03250 ACXB30C09930
8 FLARE NUT (LIQUID) 1 CWT251048 ← ←
9 FLARE NUT (GAS) 1 CWT251032 CWT251033 ←
10 CLIP FOR SENSOR 1 CWH711019 ← ←
11 CONTROL BOARD CASING 1 ACXH10-00720 ← ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2742 CWA28C2743 ← O
13 PARTICULAR PIECE - TERMINAL 1 CWD933138 ← CWD933137
14 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C21720 ACXA73C21730 ACXA73C21740 O
15 ELECTRONIC CONTROLLER - INDICATOR 1 ACXA73-07320 ← ← O
16 ELECTRONIC CONTROLLER - HVU 1 N0GE1F000007 ← ← O
17 INDICATOR HOLDER 1 ACXD93-01960 ← ←
17A INDICATOR HOLDER 1 ACXD93-01970 ← ←
18 SENSOR COMPLETE 1 CWA50C2122 ← ← O
19 SENSOR COMPLETE (ECO) 1 ACXA50C00940 ← ← O
20 ELECTRONIC CONTROLLER (ECO SENSOR) 1 CWA745791 ← ← O
21 ELECTRONIC CONTROLLER (ECO SENSOR) 1 CWA746206 ← ← O
22
ELECTRONIC CONTROLLER
(COMPARATOR)
1 CWA747891 ← ← O
23 LEAD WIRE - PCB ECO 1 CWA68C1985 ← ←
24 CONTROL BOARD CASING FOR PCB ECO 1 ACXD93-01910 ← ←
25 CONTROL BOARD CASING FOR PCB ECO 1 CWD933930 ← ←
26 CONTROL BOARD TOP COVER 1 ACXH13-00430 ← ←
27 CONTROL BOARD FRONT COVER CO. 1 ACXH13C00150 ← ←
28 DISCHARGE GRILLE COMPLETE 1 ACXE20C01170 ← ←
29 BACK COVER CHASSIS 1 CWD933463A ← ←
30 FULCRUM 2 ACXH62-00080 ← ←
31 VERTICAL VANE 11 ACXE24-00400 ← ←
32 CONNECTING BAR 1 ACXE26-00190 ← ←
33 CONNECTING BAR 1 ACXE26-00200 ← ←
34 HORIZONTAL VANE COMPLETE 1 ACXE24C00750 ← ←
35 HORIZONTAL VANE COMPLETE 1 ACXE24C01080 ← ←
36 AIR SWING MOTOR 1 ACXA98K00030 ← ← O
37 AIR SWING MOTOR 1 CWA981299 ← ← O
38 AIR SWING MOTOR 1 CWA981304 ← ← O
39 CAP - DRAIN TRAY 1 CWH521259 ← ←
40 REMOTE CONTROL COMPLETE 1 ACXA75C03550 ← ← O
41 FRONT GRILLE COMPLETE 1 ACXE10C02970 ← ← O
42 INTAKE GRILLE COMPLETE 1 ACXE22K00190 ← ←
43 GRILLE DOOR COMPLETE 1 ACXE14C00060 ← ←
44 AIR FILTER 2 ACXD00-00250 ← ← O
45 SCREW - FRONT GRILLE 4 XTT4+16CFJ ← ←
46 CAP - FRONT GRILLE 3
ACXH52-
00100A
← ←
