Panasonic CS-S9MKQ Service Manual

7
Indoor CS-S18MKQ CS-S24MKQ
Model
Outdoor CU-S18MKQ CU-S24MKQ
Performance Test Condition JIS JIS
Phase, Hz Single, 60 Single, 60
Power Supply
V 220 230 220 230
Min. Mid. Max. Min. Mid. Max. Min. Mid. Max. Min. Mid. Max.
kW 1.10 5.20 6.00 1.10 5.20 6.00 1.12 6.00 7.10 1.12 6.00 7.10
BTU/h 3750 17700 20500 3750 17700 20500 3820 20500 24200 3820 20500 24200
Capacity
kJ/h 3960 18720 21600 3960 18720 21600 4030 21600 25560 4030 21600 25560
Running Current A - 6.4 - - 6.2 - - 7.7 - - 7.4 -
Input Power W 290 1.38k 1.68k 290 1.38k 1.68k 320 1.65k 2.00k 320 1.65k 2.00k
W/W 3.79 3.77 3.57 3.79 3.77 3.57 3.50 3.64 3.55 3.50 3.64 3.55
BTU/hW 12.93 12.83 12.20 12.93 12.83 12.20 11.94 12.42 12.10 11.94 12.42 12.10
EER
kJ/hW 13.66 13.57 12.86 13.66 13.57 12.86 12.59 13.09 12.78 12.59 13.09 12.78
Power Factor % - 98 - - 97 - - 97 - - 97 -
Indoor Noise (H / L / QLo) dB-A 45 / 36 / 33 45 / 36 / 33 46 / 37 / 34 46 / 37 / 34
Cooling
Outdoor Noise (H / L) dB-A 49 / - / - 50 / - / - 49 / - / - 50 / - / -
Max Current (A) / Max Input Power (W) 8.9 / 1.93k 10.9 / 2.30k
Starting Current (A) 6.4 7.7
Type Hermetic Motor Hermetic Motor
Motor Type Brushless (4 poles) Brushless (4 poles)
Compressor
Output Power W 900 900
Type Cross-Flow Fan Cross-Flow Fan
Material ASG30K1 ASG30K1
Motor Type Transistor (8-poles) Transistor (8-poles)
Input Power W 69.5 89.5
Output Power W 40 40
QLo rpm 900 970
Lo rpm 980 1050
Me rpm 1140 1220
Hi rpm 1300 1400
Indoor Fan
Speed
SHi rpm 1400 1480
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type Induction (6-poles) Induction (6-poles)
Input Power W - -
Output Power W 66 66
Outdoor Fan
Speed Hi rpm 730 - 760 730 - 760
Moisture Removal L/h (Pt/h) 2.9 (6.1) 3.3 (7.0)
QLo m
3
/min (ft
3
/min) 11.5 (406) 11.7 (413)
Lo m
3
/min (ft
3
/min) 12.8 (452) 13.0 (459)
Me m
3
/min (ft
3
/min) 15.5 (547) 15.7 (554)
Hi m
3
/min (ft
3
/min) 18.1 (640) 18.5 (650)
Indoor Airflow
SHi m
3
/min (ft
3
/min) 19.7 (696) 19.8 (699)
Outdoor Airflow Hi m
3
/min (ft
3
/min) 39.1 (1380) 40.9 (1440) 39.1 (1380) 40.9 (1440)
Control Device Expansion Valve Capillary Tube
Refrigerant Oil cm
3
FV50S (450) FV50S (450)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.18k (41.7) R410A, 1.42k (50.1)
