Panasonic CS-TZ35ZKEW

215
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-TZ42ZKEW CS-TZ50ZKEW REMARK
1 CHASSIS COMPLETE 1 ACXD50C04620 ←
2 FAN MOTOR 1 L6CBYYYL0311 ← O
3 CROSS-FLOW FAN COMPLETE 1 ACXH02C01190 ←
4 BEARING ASSY 1 CWH64K1006 ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ←
6 EVAPORATOR 1 ACXB30C36720 ← O
7 FLARE NUT (LIQUID) 1 CWT251063 ←
8 FLARE NUT (GAS) 1 CWT251032 ←
10 CONTROL BOARD CASING 1 ACXH10-07900 ←
11 TERMINAL BOARD COMPLETE 1 ACXA28C05900 ACXA28C05970 O
12 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C90670 ACXA73C90680 O
13 ELECTRONIC CONTROLLER-INDICATOR 1 ACXA73-34560 ← O
14 INDICATOR HOLDER 1 ACXD93-20781 ←
15 SENSOR COMPLETE 1 CWA50C2664 ← O
16 ELECTRONIC CONTROLLER-WIFI 1 ACXA73-45970 ← O
19 DISCHARGE GRILLE COMPLETE 1 ACXE20C08200 ←
20 BACK COVER CHASSIS 1 ACXD93-18680 ←
21 FULCRUM 1 ACXH62-00680 ←
22 VERTICAL VANE 2 ACXE24-03470 ←
23 SHAFT 2 ACXH63-01540 ←
24 SHAFT 2 ACXH63-01570 ←
25 HORIZONTAL VANE - INNER 1 ACXE24-03710 ←
26 HORIZONTAL VANE - OUTER 1 ACXE24-03720 ←
27 AIR SWING MOTOR 1 ACXA98-03560 ← O
28 CAP - DRAIN TRAY 1 CWH521259 ←
29 REMOTE CONTROL COMPLETE 1 ACXA75C23671 ← O
30 FRONT GRILLE COMPLETE 1 ACXE10C16850 ←
31 INTAKE GRILLE ASSY 1 ACXE22C04140 ←
32 GRILLE DOOR COMPLETE 1 ACXE14C01340 ←
33 AIR FILTER 2 ACXD00-02860 ←
34 SCREW - FRONT GRILLE 4 XTT4+16CFJ ←
35 DRAIN HOSE 1 ACXH85-00201 ←
36 INSTALLATION PLATE 1 ACXH36-00650 ←
37 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
38 TUBE ASSY-COMPLETE 1 ACXT00C43120 ←
39 BOX SHAPED PLATE 1 ACXD66-02910 ←
40 LEAD WIRE-COMPLETE -WIFI 1 ACXA60C96480 ← O
41 GENERATOR COMPLETE 1 ACXH94C01590 ← O
42 PARTICULAR PLATE -LOCK 3 ACXD93-18690 ←
43 OPERATING INSTRUCTION 1 ACXF55-33990 ←
44 OPERATING INSTRUCTION 1 ACXF55-34000 ←
45 INSTALLATION INSTRUCTION 1 ACXF60-47630 ←
46 INSTALLATION INSTRUCTION 1 ACXF60-47640 ←
47 INSTALLATION INSTRUCTION 1 ACXF60-47650 ←
48 INSTALLATION INSTRUCTION 1 ACXF60-47660 ←
49 INSTALLATION INSTRUCTION 1 ACXF60-47670 ←
50 INSTALLATION INSTRUCTION 1 ACXF60-47680 ←
