Panasonic CS-TZ35ZKEW

220
SAFETY REF. NO. PART NAME & DESCRIPTION QTY.
CS-TZ60ZKEW CS-TZ71ZKEW REMARK
1 CHASSIS COMPLETE 1 ACXD50C04180 ←
2 FAN MOTOR 1 L6CBYYYL0376 ← O
3 CROSS-FLOW FAN COMPLETE 1 ACXH02C01450 ←
4 BEARING ASSY 1 CWH64K1006 ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ←
6 FAN MOTOR BRACKET 1 ACXD54-04360 ←
8 EVAPORATOR 1 ACXB30C33300 ACXB30C35590 O
9 FLARE NUT (LIQUID) 1 CWT251048 ←
10 FLARE NUT (GAS) 1 CWT251032 CWT251033
11 CONTROL BOARD TOP COVER 1 ACXH13-08680 ACXH13-08680
12 ELECTRONIC CONTROLLER-WIFI 1 ACXA73-45970 ← O
13 CONTROL BOARD CASING 1 ACXH10-08620 ←
14 TERMINAL BOARD COMPLETE 1 ACXA28C05970 ← O
15 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C91620 ACXA73C91630 O
16 ELECTRONIC CONTROLLER-INDICATOR 1 ACXA73-45790 ← O
18 GENERATOR COMPLETE 1 ACXH94C01530 ← O
19 INDICATOR HOLDER 1 ACXD93-22810 ←
20 SENSOR COMPLETE 1 ACXA50C17750 CWA50C2664 O
21 DISCHARGE GRILLE COMPLETE 1 ACXE20C08220 ←
22 BACK COVER CHASSIS 1 ACXD93-22420 ←
23 FULCRUM 2 ACXH62-00810 ←
24 VERTICAL VANE 10 ACXE24-04000 ←
25 CONNECTING BAR - LEFT 2 ACXE26-02640 ←
26 CONNECTING BAR - RIGHT 2 ACXE26-02650 ←
27 HORIZONTAL VANE COMP - OUTER 1 ACXE24C04910 ←
28 HORIZONTAL VANE COMP - INNER 1 ACXE24C04760 ←
29 AIR SWING MOTOR ASSY 1 ACXA98K00220 ← O
30 AIR SWING MOTOR - OUTER VANE 1 ACXA98-03560 ← O
31 AIR SWING MOTOR - INNER VANE 1 ACXA98-02950 ← O
32 CAP - DRAIN TRAY 1 CWH521259 ←
33 REMOTE CONTROL COMPLETE 1 ACXA75C24381 ← O
34 FRONT GRILLE COMPLETE 1 ACXE10C16960 ACXE10C16970
35 INTAKE GRILLE COMPLETE 1 ACXE22C04730 ←
36 GRILLE DOOR COMPLETE 1 ACXE14C01440 ←
37 AIR FILTER 2 ACXD00-03070 ←
38 SCREW - FRONT GRILLE 6 XTT4+16CFJ ←
39 CAP - FRONT GRILLE 3 ACXH52-04000 ←
40 PARTICULAR PLATE -LOCK 4 ACXD93-18690 ←
43 DRAIN HOSE 1 ACXH85-00211 ←
44 BOX SHAPED PLATE 1 ACXD66-03490 ←
45 TUBE ASSY-COMPLETE 1 ACXT00C35810 ACXT00C39160
47 LEAD WIRE-COMPLETE -WIFI 1 ACXA60C94030 ← O
49 INSTALLATION PLATE 1 ACXH36-00880 ←
50 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
51 OPERATING INSTRUCTION 1 ACXF55-34010 ←
52 OPERATING INSTRUCTION 1 ACXF55-34020 ←
53 INSTALLATION INSTRUCTION 1 ACXF60-47740 ←
