Panasonic CS-TZ35ZKEW - Page 27

27
Model
Indoor CS-RZ35ZKEW CS-RZ50ZKEW
Outdoor CU-RZ35ZKE CU-RZ50ZKE
Performance Test Condition EUROVENT EUROVENT
Power Supply
Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.85 3.50 4.00 0.98 5.00 5.50
BTU/h 2900 11900 13600 3340 17100 18800
kcal/h 730 3010 3440 840 4300 4730
Running Current A – 4.40 – – 7.00 –
Input Power W 235 1.00k 1.22k 250 1.60k 1.89k
Annual Consumption kWh – 500 - – 800 –
EER
W/W 3.62 3.50 3.28 3.92 3.13 2.91
BTU/hW 12.34 11.90 11.15 13.36 10.69 9.95
kcal/hW 3.11 3.01 2.82 3.36 2.69 2.50
ErP
Pdesign kW 3.5 5.0
SEER (W/W) 6.4 6.9
Annual
Consumption
kWh 191 254
Class A++ A++
Power Factor % – 99 – – 99 –
Indoor Noise (H / L / QLo)
Pressure Level
(dB(A)
42 / 30 / 20 44 / 37 / 33
Power Level dB 58 / – / – 60 / – / –
Outdoor Noise (H / L)
Pressure Level
(dB(A)
48 / – 48 / –
Power Level dB 63 / – 63 / –
Heating
Capacity
kW 0.80 4.00 5.10 0.98 5.80 7.50
BTU/h 2730 13600 17400 3340 19800 25600
kcal/h 690 3440 4390 840 4990 6450
Running Current A – 4.60 – – 7.60 –
Input Power W 195 1.05k 1.42k 210 1.70k 2.30k
COP
W/W 4.10 3.81 3.59 4.67 3.41 3.26
BTU/hW 14.00 12.95 12.25 15.90 11.65 11.13
kcal/hW 3.54 3.28 3.09 4.00 2.94 2.80
ErP
Pdesign kW 2.8 4.0
Tbivalent °C -10 -10
SCOP (W/W) 4.6 4.4
Annual
Consumption
kWh 852 1273
Class A++ A+
Power Factor % – 99 – – 97 –
Indoor Noise (H / L / QLo)
Pressure Level
(dB(A)
42 / 33 / 22 44 / 37 / 33
Power Level dB 58 / – / – 60 / – / –
Outdoor Noise (H / L)
Pressure Level
(dB(A)
50 / – 49 / –
Power Level dB 65 / – 64 / –
Low Temp. : Capacity (kW) / I.Power (W) / COP 3.70 / 1.26k / 2.94 5.43 / 2.04k / 2.66
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 3.30 / 1.35k / 2.44 4.62 / 2.00k / 2.31
Max Current (A) / Max Input Power (W) 6.3 / 1.42k 10.5 / 2.30k
Starting Current (A) 4.60 7.60
