CS-W24BD2P, CS-W28BD2P, CS-W34BDP, CS-W43BD2P
REF. NO. PARTS NAME PARTS NUMBER QUANTITY PER 1 UNIT
CS-W24BD2P CS-W28BD2P CS-W34BD2P CS-W43BD2P
1 Cabinet (Bottom) P42-T02170 ---- ---- 1 1
P42-T03010 1 1 ---- ----
2 Drain pan P42-T02370 1 1 ---- ----
P42-T02700 ---- ---- 1 1
3 Evaporator P45-T07300 1 1 ---- ----
P45-T07310 ---- ---- 1 ----
P45-T07320 ---- ---- ---- 1
4 Distributor ass’y. P45-T07150 1 ---- ---- ----
P45-T07160 ---- 1 ---- ----
P45-T07170 ---- ---- 1 ----
P45-T07180 ---- ---- ---- 1
5 Cabinet (Top) P02-T07490 ---- ---- 1 1
P02-T07570 1 1 ---- ----
6 Cabinet (Rear) P42-T03380 1 1 ---- ----
P42-T03400 ---- ---- 1 1
7 Duct flange ass’y. P42-T02150 ---- ---- 1 1
(Outlet) P42-T02390 1 1 ---- ----
8 Fan Base ass’y P45-T04270 ---- ---- 1 1
P45-T04490 1 1 ---- ----
9 Casing ass’y P45-T04260 ---- ---- 2 2
10 Casing R ass’y. P45-T06760 1 1 ---- ----
11 Casing L ass’y. P45-T06770 1 1 ---- ----
12 Fan motor P06-T04311 1 1 ---- ----
P06-T04321 ---- ---- 1 ----
P06-T04331 ---- ---- ---- 1
13 Panel side R ass’y. P42-T02980 ---- ---- 1 1
P42-T03300 1 1 ---- ----
14 Panel side L ass’y. P42-T02200 ---- ---- 1 1
P42-T03000 1 1 ---- ----
15 Terminal board P06-T04680 1 1 1 1
16 Capacitor P06-T04630 1 ---- ---- 1
P06-T04640 ---- 1 1 ----
P06-T04660 ---- ---- ---- 1
17 Transformer P06-T04300 1 1 1 1
18 Remote control (P) A75C2240 1 1 1 1
19 Thermistor ass’y. 06-854510 1 1 1 1
20 Coil sensor 06-853760 1 1 1 1
21 PCB assembly A53D003A 1 1 1 1
22 Noise filter A491018 1 1 1 1
(P46-T06120
23 PCB fuse (250V T3.15A) ---- 1 1 1 1
24 Fuse (250V T5A) P06-T04740 ---- ---- 1 1
All parts are supplied by Taiwan (Tamaco).
121
