Panasonic CS-W24BD2P Service Manual

14 COMPONENT SPECIFICATION
Compressor
Models Heat pump
model
50Hz CU-W24BBP5 CU-W28BBP5
CU-W28BBP8
CU-W34BBP8 CU-W43BBP8
Cooling only
model
50Hz CU-V24BBP5
CU-V24BBP8
CU-V28BBP5
CU-V28BBP8
CU-V34BBP8 CU-V43BBP8
60Hz - - - -
Compressor Model single-phase NE41VNHMT NE44VNHMT ZR48KCE-TFD ZR57KCE-TFD
3-phase NE41YDNMT NE44YDNMT - -
Compressor Type
No. of Cylinders
ROTARY SCROLL
1 1 1 1
Revolution r/min. 2,900 2,900 2,900 2,900
Piston Displacement m
3
/min. 7.27 7.73 11.39 13.42
Motor Type
Starting Method Direct on-line Starting
Rated Output kW 1.9 2.0 3.0 3.5
Poles
Insulation Glass
2
E
2
E
2
E
2
E
Revolution MEL56 MEL56 MEL56 MMMAPOE MMMAPOE
Revolution L 1.3 1.3 1.3 2.0
Evaporator
Models (Cooling Only Model) CS-W24BD2P CS-W28BD2P CS-W34BD2P CS-W43BD2P
Tube Material Copper Tube
Outer Diameter mm 9.5 9.5 9.5 9.5
Thickness mm 0.28 0.28 0.28 0.28
Row 3 3 2 3
No. of Tubes/Row 10 10 16 16
Fin Material Aluminium
Thickness mm 0.11 0.11 0.11 0.11
Fin Pitch No./inch 14 14 14 14
Fin Surface Louvre-fin Louvre-fin Louvre-fin Louvre-fin
Total Face Area m
2
0.218 0.218 0.358 0.358
Evaporator Fan Sirocco Fan
Type
No./Unit 2 2 2 2
Evaporator Fan motor Direct On-Line Starting
Starting
Rated Output kW 0.075 0.075 0.25 0.35
Poles 4 4 4 4
Phase Single-Phase Single-Phase Single-Phase Single-Phase
Insulation E E E E
55
