Panasonic CS-W24BD2P Service Manual

4 SPECIFICATION (COOLING ONLY TYPE)
4.1. CS-W24BD2P / CU-V24BBP5
ITEM / MODEL Indoor Unit Outdoor unit
Main Body CS-W24BD2P CU-V24BBP5
Cooling Capacity kW 6.30
(BTU/h) (21,500)
Refrigerant Charge-less m 30
Standard Air Volume for High Speed m
3
/min Hi 18 -
cfm Hi 636
External Static Pressure mmAq Hi 10 -
Pa Hi 98
Air Inlet Backward Suction Back sided Suction
Air Outlet Front blow-out Front blow-out
Outside Dimension (H x W x D) mm 290 x (1000 + 100) x 500 900 x 900 x 320
Net Weight kg (lbs) 43 (95) 80 (176)
Piping Connection Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 6.35 (1/4) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor Type, Number of Set - Hermetic-1 (Rotary), 1
Starting Method - Direct on-line starting
Motor Type - 2-pole single phase induction motor
Rated Output kW - 1.9
Fan Type, Number of Set Sirocco fan Prop. fan
Air Volume Control Three-Step and Auto mode -
(Remote Control)
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.15 0.05
Air-heat Exchanger Louvre-fin type X-Louvre-fin type
Refrigerant Control Capillary tube Capillary tube
Refrigerant Oil (Charged) L - MEL56 (1.3)
Refrigerant (Charged) kg (oz) - R407C 2.8 (99)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal thermostat for F.M, Crankcase
heater, High pressure switch, Current Transformer
Noise Level dB (A) Hi 40 Lo 36 52
Power level dB Hi 55 Lo 51 65
1. Cooling capacities are based on indoor temp. 27°C D.B (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air temp. 35°C
D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
ELECTRICAL DATA (50Hz)
MODEL / ITEM CS-W24BD2P/CU-V24BBP5
Condition by JIS B 8615
Volts V 220 230 240
Phase Single Single Single
Input Power kW Cool 2.56 2.56 2.56
Running Current A Cool 11.70 11.20 10.80
Starting Current A 64 66 68
Power Factor % Cool 99 99 99
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V 50Hz
14

Panasonic CS-W24BD2P Specifications

General

Brand	Panasonic
Model	CS-W24BD2P
Category	Air Conditioner
Language	English
