Panasonic CS-W24BD2P Service Manual

15 CAPACITY AND POWER CONSUMPTION
■
■■
■
PERFORMANCE DATA
COOLING PERFORMANCE
Model Cooling capacities are based conditions
CS-W24BD2P
●
Indoor temp. 27°C D.B. 19°C W.B.
●
Outdoor temp. 35°C D.B.
●
Standard air volume 18 m
3
/min
●
External Static Pressure (98Pa)
Cooling capacity
6.3kW
Entering Temperature Air Entering Condenser (°C D.B.)
Air 25°C 30°C 35°C 40°C 43°C
Temperature TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
D.B. W.B. kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
17 6.56 4.39 2.17 6.30 1.50 2.29 5.93 4.21 2.46 5.48 4.00 2.66 5.10 3.82 2.74
23 19 6.93 3.67 2.30 2.31 1.26 2.43 6.37 3.63 2.61 5.94 3.50 2.82 5.57 3.40 2.90
22 7.56 3.10 2.48 2.52 1.07 2.62 7.02 3.16 2.82 6.57 3.09 3.04 6.18 3.03 3.07
17 6.48 5.12 2.16 4.16 1.75 2.29 5.87 4.87 2.46 5.44 4.63 2.64 5.10 4.44 2.73
25 19 6.93 4.51 2.30 4.49 1.54 2.44 6.33 4.37 2.62 5.90 4.19 2.81 5.55 4.06 2.90
22 7.56 3.70 2.48 4.89 1.26 2.63 6.97 3.69 2.83 6.25 3.44 3.01 6.16 3.51 3.03
17 6.40 6.08 2.15 6.16 5.97 2.29 5.81 5.81 2.46 5.40 5.40 2.63 5.11 5.11 2.72
27 19 6.94 5.28 2.30 6.68 5.21 2.45 6.30 5.04 2.63 5.86 4.80 2.81 5.54 4.66 2.91
22 7.55 4.31 2.48 7.30 4.31 2.64 6.92 4.22 2.84 5.94 3.74 3.04 6.14 3.99 3.08
17 6.39 6.07 2.14 6.16 5.97 2.27 5.83 5.83 2.42 5.44 5.44 2.59 5.17 5.17 2.68
29 19 6.93 6.37 2.28 6.68 6.28 2.42 6.32 6.07 2.59 5.91 5.79 2.76 5.61 5.61 2.86
22 7.52 5.04 2.51 7.27 5.01 2.67 6.89 4.89 2.85 6.24 4.55 3.02 6.14 4.60 3.08
17 6.38 6.06 2.13 6.16 5.97 2.25 5.84 5.84 2.40 5.47 5.47 2.56 5.22 5.22 2.65
32 19 6.92 6.57 2.27 6.68 6.48 2.41 6.33 6.33 2.56 5.94 5.94 2.73 5.66 5.66 2.83
22 7.50 6.23 2.54 7.25 6.16 2.69 6.87 5.97 2.86 6.44 5.73 3.05 6.14 5.58 3.16
Model Cooling capacities are based conditions
CS-W28BD2P
●
Indoor temp. 27°C D.B. 19°C W.B.
●
Outdoor temp. 35°C D.B.
●
Standard air volume 20 m
3
/min
●
External Static Pressure (98Pa)
Cooling capacity
7.1kW
Entering Temperature Air Entering Condenser (°C D.B.)
Air 25°C 30°C 35°C 40°C 43°C
Temperature TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
D.B. W.B. kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
17 7.39 4.95 2.30 7.10 4.90 2.43 6.68 4.74 2.61 6.18 4.51 2.82 5.74 4.31 2.93
23 19 7.81 4.14 2.44 7.56 4.16 2.58 7.18 4.09 2.77 6.69 3.95 2.96 6.27 3.83 3.05
22 8.52 3.49 2.63 8.29 3.57 2.78 7.91 3.56 2.99 7.41 3.48 3.12 6.97 3.41 3.14
17 7.30 5.77 2.29 7.02 5.69 2.43 6.61 5.49 2.61 6.13 5.21 2.79 5.75 5.00 2.87
25 19 7.81 5.08 2.44 7.54 5.05 2.59 7.14 4.93 2.78 6.65 4.72 2.95 6.26 4.57 3.03
22 8.52 4.17 2.63 8.26 4.21 2.79 7.86 4.16 3.00 7.05 3.88 3.02 6.95 3.96 3.06
17 7.21 6.85 2.28 6.94 6.73 2.43 6.55 6.55 2.61 6.09 6.09 2.75 5.76 5.76 2.82
27 19 7.82 5.95 2.44 7.53 5.87 2.59 7.10 5.68 2.79 6.60 5.41 2.94 6.25 5.25 3.01
22 8.51 4.85 2.63 8.23 4.85 2.80 7.80 4.76 3.01 6.69 4.21 3.11 6.92 4.50 3.13
17 7.20 6.84 2.27 6.94 6.73 2.41 6.57 6.57 2.57 6.14 6.14 2.67 5.83 5.83 2.81
29 19 7.81 7.18 2.42 7.53 7.08 2.57 7.12 6.84 2.75 6.66 6.52 2.86 6.32 6.32 3.01
22 8.48 5.68 2.67 8.19 5.65 2.83 7.76 5.51 3.03 7.03 5.13 3.03 6.92 5.19 3.17
17 7.19 6.83 2.26 6.94 6.73 2.39 6.58 6.58 2.54 6.17 6.17 2.62 5.88 5.88 2.81
32 19 7.80 7.41 2.41 7.53 7.30 2.55 7.14 7.14 2.72 6.69 6.69 2.80 6.38 6.38 3.00
22 8.46 7.02 2.69 8.17 6.94 2.85 7.74 6.73 3.04 7.26 6.46 3.12 6.92 6.29 3.35
57
