Condenser
Models Heat pump model CU-W24BBP5 CU-W28BBP5
CU-W28BBP8
CU-W34BBP5
CU-W34BBP8
CU-W43BBP8
Cooling only model CU-V24BBP5 CU-V28BBP5 CU-V34BBP5 CU-V43BBP8
CU-V24BBP8 CU-V28BBP8 CU-V34BBP8
Tube Material Copper tube
Outer Diameter mm 9.52 9.52 9.52 9.52
Thickness mm 0.3 0.3 0.3 0.3
Row 2 2 2 2
No. of Tubes/Row 34 34 46 46
Fin Material Aluminium
Thickness mm 0.105 0.105 0.105 0.105
Fin Pitch No./inch 14 14 14 14
Fin Surface X-Louvre-fin X-Louvre-fin X-Louvre-fin X-Louvre-fin
Total Face Area m
2
0.61 0.61 0.82 1.05
Fan
Type Propeller Fan
No.of unit 1 1 2 2
Fan Motor
Starting Method Direct on-line Starting
Rated Output kW 0.055 0.055 0.055 X 2 0.055 X 2
Poles 6 6 6 6
Phase Single-Phase Single-Phase Single-Phase Single-Phase
Insulation Class E E E E
56
