Panasonic CS-W24BD2P Service Manual

CU-V24BBP5, CU-V24BBP8, CU-V28BBP5, CU-V28BBP8
NO. PART DESCRIPTION QTY. CU-V24BBP5 CU-V24BBP8 CU-V28BBP5 CU-V28BBP8
1 BASE PAN ASS’Y 1 CWD52K1038A
←
←←
← ←
←←
← ←
←←
←
2 COMPRESSOR 1 NE41VNHMT NE41YDNMT NE44VNHMT NE44YDNMT
3 ANTI-VIBRATION BUSHING 4 CWH501018
←
←←
← ←
←←
← ←
←←
←
4 NUT FOR COMP. MOUNT. 3 XNG8
←
←←
← ←
←←
← ←
←←
←
4a WASHER for COMPRESSOR 3 XWA8
←
←←
← ←
←←
← ←
←←
←
4b SP WASHER 3 CWH571018
←
←←
← ←
←←
← ←
←←
←
5 CRANKCASE HEATER 1 CWA341005
←
←←
← ←
←←
← ←
←←
←
6 CONDENSER COMPLETE 1 CWB32C1189
←
←←
←
CWB32C1190
←
←←
←
7 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1078
←
←←
←
CWT07K1081
←
←←
←
8 PIPE HOLDER RUBBER 1 CWG251016
←
←←
← ←
←←
← ←
←←
←
9 CONDENSER SIDE PLATE 1 CWD911122
←
←←
← ←
←←
← ←
←←
←
11 TUBE ASS’Y (PRESSURE SWITCH) 1 CWT022584
←
←←
← ←
←←
← ←
←←
←
12 HIGH PRESSURE SWITCH 1 CWA101003
←
←←
← ←
←←
← ←
←←
←
13 ACCUMULATOR 1 CWB131007A
←
←←
←
CWB131008A
←
←←
←
14 TUBE ASS’Y (3 WAYS VALVE) 1 CWT022585
←
←←
←
CWT022591
←
←←
←
15 TUBE ASS’Y (VALVE+STRAINER) 1 CWT022583
←
←←
←
CWT022589
←
←←
←
16 3-WAYS VALVE 1 CWB011087
←
←←
← ←
←←
← ←
←←
←
17 STRAINER 1 NOT AVAILABLE
←
←←
← ←
←←
← ←
←←
←
17a 2-WAYS VALVE 1 - - CWB02299
←
←←
←
18 CAPILLARY TUBE for VALVE 1 CWB15K1065
←
←←
←
CWB15K1068
←
←←
←
19 PIPE HOLDER RUBBER 1 CWG251013 NOT AVAILABLE CWG251013
←
←←
←
20 HOLDER-SERVICE VALVE 1 CWD911124
←
←←
← ←
←←
← ←
←←
←
21 SOUND-PROOF BOARD ASS’Y 1 CWH151016
←
←←
← ←
←←
← ←
←←
←
21a SOUND PROOF MATERIAL-COMP 1 CWG302098
←
←←
← ←
←←
← ←
←←
←
22 V-COIL COMPLETE 1 - - CWA43C2068
←
←←
←
23 PIPING SENSOR (DISCHARGE) 1 CWA501042
←
←←
← ←
←←
← ←
←←
←
24 PIPING SENSOR (COIL) 1 CWA501043
←
←←
← ←
←←
← ←
←←
←
25 SPRING FOR SENSOR 2 CWH711010
←
←←
← ←
←←
← ←
←←
←
26 CABINET REAR PLATE 1 CWE02C1005
←
←←
← ←
←←
← ←
←←
←
27 CONTROL BOARD 1 CWH141004
←
←←
← ←
←←
← ←
←←
←
28 COMPRESSOR RELAY 1 CWA001005 CWA001007 CWA001005 CWA001007
29 TERMINAL BOARD ASS’Y 1 CWA28K1027 CWA28K1029 CWA28K1027 CWA28K1029
30 CAPACITOR-FAN MOTOR 1 DS461305QP-A
(3.0/460)
←
←←
← ←
←←
← ←
←←
←
30a CAPACITOR-COMP (MF/V) 1 DS441456CPNB
(45/440)
- DS441506CPNB
(50/440)
-
31 ELECTRONIC CONTROLLER 1 CWA742587 CWA742588 CWA742587 CWA742588
32 TRANSFORMER 1 CWA401029
←
←←
← ←
←←
← ←
←←
←
33 CURRENT TRANSFORMER BOARD 1 CWA742592
←
←←
←
CWA742591 CWA742592
33a OVERLOAD PROTECTOR 1 - CWA121075 - CWA121075
33b TERMINAL COVER 1 CWH171019 CWH171022 CWH171019 CWH171022
34 BRACKET FAN MOTOR 1 CWD541027
←
←←
← ←
←←
← ←
←←
←
35 SCREW-BRACKET FAN MOTOR 4 CWH551040
←
←←
← ←
←←
← ←
←←
←
36 FAN MOTOR 1 CWA951078
←
←←
← ←
←←
← ←
←←
←
38 SCREW-FAN MOTOR 4 CWH55442
←
←←
← ←
←←
← ←
←←
←
39 PROPELLER FAN 1 CWH001007
←
←←
← ←
←←
← ←
←←
←
40 WASHER for P.FAN 1 CWH571013
←
←←
← ←
←←
← ←
←←
←
41 SPRING WASHER for P.FAN 1 XWB10B
←
←←
← ←
←←
← ←
←←
←
42 NUT for PROPELLER FAN 1 CWH56033
←
←←
← ←
←←
← ←
←←
←
43 P.FAN AIR GUIDER PLATE 1 CWE061036A
←
←←
← ←
←←
← ←
←←
←
44 FAN GUARD 1 CWD041014A
←
←←
← ←
←←
← ←
←←
←
45 CONDENSER GUARD 1 CWD041015A
←
←←
← ←
←←
← ←
←←
←
46 CABINET TOP PLATE COMPLETE 1 CWE03C1004
←
←←
← ←
←←
← ←
←←
←
47 FLARE NUT (1/4”) / (3/8”) 1 CWH6002140
←
←←
←
CWT25005
←
←←
←
48 FLARE NUT (5/8”) 1 CWT25004
←
←←
← ←
←←
← ←
←←
←
49 PIPE COVER (FRONT) 1 CWD601017A
←
←←
← ←
←←
← ←
←←
←
50 PIPE COVER (BACK) 1 CWD601018A
←
←←
← ←
←←
← ←
←←
←
51 CABINET FRONT PLATE 1 CWE06C1033
←
←←
← ←
←←
← ←
←←
←
52 HANDLE 3 CWE161008
←
←←
← ←
←←
← ←
←←
←
53 HANDLE 1 CWE161009
←
←←
← ←
←←
← ←
←←
←
54 LEADWIRE-COMPRESSOR 1 CWA67C3657 CWA67C3665 CWA67C3657 CWA67C3665
55 ACCESSORY COMPLETE 1 CWH82C1105
←
←←
← ←
←←
← ←
←←
←
INSTALLATION INSTRUCTION 1 CWF612270
←
←←
← ←
←←
← ←
←←
←
56 DRYER 1 CWB101013
←
←←
←
CWB101014
←
←←
←
All parts are supplied from MACC Malaysia (Vendor Code : 086)
127
