Panasonic CS-W24BD2P Service Manual

CU-W34BBP8, CU-W43BBP8
NO. PART DESCRIPTION QTY. CU-W34BBP8 CU-W43BBP8
1 BASE PAN ASS’Y 1 CWD52K1039A CWD52K1040A
2 COMPRESSOR 1 ZR48KCE-TFD ZR57KCE-TFD
3 ANTI-VIBRATION BUSHING 4 CWH501020
←
←←
←
4 NUT FOR COMP. MOUNT. 3 CWH4582065
←
←←
←
5 CRANKCASE HEATER 1 CWA341004 CWA341002
6 CONDENSER COMPLETE 1 CWB32C1196 CWB32C1197
7 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1075 CWT07K1076
8 PIPE HOLDER RUBBER 1 CWG251016 CWG251021
9 CONDENSER SIDE PLATE 1 CWD911123
←
←←
←
10 CONDENSER TOP PLATE 1 CWD911132 CWD911133
11 TUBE ASS’Y (PRESSURE SWITCH) 1 CWT022615 CWT022618
12 HIGH PRESSURE SWITCH 1 CWA101003
←
←←
←
13 ACCUMULATOR 1 CWB13K1022 CWB13C1020
13b TUBE ASS’Y (PRESS.SW + VALVE) 1 CWT022617 CWT022620
13c HEATING PRESSURE SWITCH CWA101004
←
←←
←
13d 4-WAYS VALVE 1 CWB001014 CWB001015
15 TUBE ASS’Y (VALVE+STRAINER) 1 CWT022629
←
←←
←
16 3-WAYS VALVE CWB011091
←
←←
←
17 STRAINER CWB111005
←
←←
←
17a 2-WAYS VALVE CWB02299
←
←←
←
18 CAPILLARY TUBE for VALVE 1 CWB15K1037 CWB15K1039
19 PIPE HOLDER RUBBER 1 CWG251015
←
←←
←
20 HOLDER-SERVICE VALVE 1 CWD911131
←
←←
←
21 SOUND-PROOF BOARD ASS’Y 1 CWH15K1010
←
←←
←
21a SOUND PROOF MATERIAL-COMP. 1 CWG302101 CWG302103
22 V-COIL COMPLETE 1 CWA43C2067
←
←←
←
22a V-COIL COMPLETE-4 WAY VALVE 1 CWA43C2063
←
←←
←
23 PIPING SENSOR (DISCHARGE) 1 CWA501044
←
←←
←
24 PIPING SENSOR (COIL) 1 CWA501045
←
←←
←
25 SPRING FOR SENSOR 2 CWH711010
←
←←
←
26 CABINET REAR PLATE 1 CWE021012A CWE02C1010
27 CONTROL BOARD 1 CWH141004
←
←←
←
28 COMPRESSOR RELAY 1 CWA001005
←
←←
←
29 TERMINAL BOARD ASS’Y 1 CWA28K1029
←
←←
←
30 CAPACITOR-FAN MOTOR 2 DS461305QP-A (3.0/460) DS461355QP-A (3.5/460)
31 ELECTRONIC CONTROLLER 1 CWA742585
←
←←
←
32 TRANSFORMER 1 CWA401029
←
←←
←
33 CURRENT TRANSFORMER BOARD 1 CWA742592
←
←←
←
34 BRACKET-FAN MOTOR 1 CWD541028
←
←←
←
35 SCREW-BRACKET FAN MOTOR 4 CWH551040
←
←←
←
36 FAN MOTOR 2 CWA951078
←
←←
←
38 SCREW-FAN MOTOR 8 CWH55442
←
←←
←
39 PROPELLER FAN 2 CWH001007
←
←←
←
40 WASHER for P.FAN 2 CWH571013
←
←←
←
41 SPRING WASHER for P.FAN 2 XWB10B
←
←←
←
42 NUT for PROPELLER FAN 2 CWH56033
←
←←
←
43 P.FAN AIR GUIDER PLATE 1 CWE061042A CWE061044A
44 FAN GUARD 2 CWD041014A
←
←←
←
45 CONDENSER GUARD 1 CWD041016A CWD041017A
46 CABINET TOP PLATE COMPLETE 1 CWE03C1004 CWE03C1005
47 FLARE NUT (3/8”) 1 CWT25005
←
←←
←
48 FLARE NUT (6/8”) 1 CWT251012
←
←←
←
49 PIPE COVER (FRONT) 1 CWD601017A
←
←←
←
50 PIPE COVER (BACK) 1 CWD601018A
←
←←
←
51 CABINET FRONT PLATE 1 CWE061046A
←
←←
←
52 HANDLE 3 CWE161008
←
←←
←
53 HANDLE 1 CWE161009
←
←←
←
54 LEADWIRE-COMPRESSOR 1 CWA67C3656
←
←←
←
55 ACCESSORY COMPLETE 1 CWH82C1105
←
←←
←
INSTALLATION INSTRUCTION 1 CWF612270
←
←←
←
56 DRYER 1 CWB101014
←
←←
←
The above parts are kept for seven years in accordance with MEI service policy.
