Panasonic CS-W24BD2P Service Manual

HEATING PERFORMANCE
Model Heating capacities are based conditions
CS-W24BD2P
●
Indoor temp. 20°C D.B.
●
Outdoor temp. 7°C D.B. 6°C W.B.
●
Standard air volume 18 m
3
/min
●
External Static Pressure (98Pa)
Heating capacity
7.1kW
Inlet Air Outdoor Temperature (°C W.B.)
External Static Pressure (Pa) Entering Air -6°C 0°C 6°C 12°C
Air Volume (m
3
/min) Dry Bulb (°C) H.C. IPT H.C. IPT H.C. IPT H.C. IPT
15 5.04 1.86 6.11 2.12 7.46 2.46 8.88 2.87
98Pa 18m
3
/min 20 4.69 2.25 5.75 2.25 7.10 2.59 8.45 3.03
25 4.33 2.07 5.40 2.38 6.75 2.72 8.09 3.10
Model Heating capacities are based conditions
CS-W28BD2P
●
Indoor temp. 20°C D.B.
●
Outdoor temp. 7°C D.B. 6°C W.B.
●
Standard air volume 20 m
3
/min
●
External Static Pressure (98Pa)
Heating capacity
8.0kW
Inlet Air Outdoor Temperature (°C W.B.)
External Static Pressure (Pa) Entering Air -6°C 0°C 6°C 12°C
Air Volume (m
3
/min) Dry Bulb(°C) H.C. IPT H.C. IPT H.C. IPT H.C. IPT
15 5.68 2.03 6.88 2.31 8.40 2.68 10.0 3.13
98Pa 20m
3
/min 20 5.28 2.45 6.48 2.45 8.00 2.82 9.52 3.30
25 4.88 2.26 6.08 2.59 7.60 2.96 9.12 3.60
Model Heating capacities are based conditions
CS-W34BD2P
●
Indoor temp. 20°C D.B.
●
Outdoor temp. 7°C D.B. 6°C W.B.
●
Standard air volume 33 m
3
/min
●
External Static Pressure (147Pa)
Heating capacity
11.2kW
Inlet Air Outdoor Temperature (°C W.B.)
External Static Pressure (Pa) Entering Air -6°C 0°C 6°C 12°C
Air Volume (m
3
/min) Dry Bulb(°C) H.C. IPT H.C. IPT H.C. IPT H.C. IPT
15 7.95 3.03 9.63 3.45 11.8 4.00 14.0 4.67
147Pa 33m
3
/min 20 7.39 3.66 9.07 3.66 11.2 4.21 13.3 4.93
25 6.83 3.37 8.51 3.87 10.6 4.42 12.8 4.83
Model Heating capacities are based conditions
CS-W43BD2P
●
Indoor temp. 20°C D.B.
●
Outdoor temp. 7°C D.B. 6°C W.B.
●
Standard air volume 36 m
3
/min
●
External Static Pressure (147Pa)
Heating capacity
14.0kW
Inlet Air Outdoor Temperature (°C W.B.)
External Static Pressure (Pa) Entering Air -6°C 0°C 6°C 12°C
Air Volume (m
3
/min) Dry Bulb(°C) H.C. IPT H.C. IPT H.C. IPT H.C. IPT
15 9.90 3.79 12.0 4.31 14.7 5.00 17.5 5.84
147Pa 36m
3
/min 20 9.24 4.58 11.3 4.58 14.0 5.26 16.7 6.15
25 8.54 4.21 10.6 4.84 13.3 5.52 16.0 6.27
59
