Airflow Direction Adjustment
Preparation Before Operation
Before operating the unit
23
■ Open the front panel.
■ Remove air filter.
■ Insert air purifying filter.
Insert the air filters.
Hold the tab to raise up
slightly and then pull down.
Hold the panel openers at both
sides and pull up the front panel.
Air
filter
■ Connect the power
supply cord to an
independent power
supply.
1
Air purifying
filter
Be careful not to
hurt your hands by
metal parts.
<Note>
Use under the following conditions :
(Unit in °C)
DBT : Dry Bulb Temperature
WBT : Wet Bulb Temperature
Maximum Temperature
Minimum Temperature
Cooling
Indoor Outdoor
DBT WBT DBT WBT
32 23 43 26
16 11 16 11
Heating
Indoor Outdoor
DBT WBT DBT WBT
30 – 24 18
16 – -5 -6
To Next Page
