Panasonic CS-YE9MKE User Manual

5
OPERATION CONDITION
Use this air conditioner under the following temperature range
Temperature (°C)
Indoor Outdoor
*DBT *WBT *DBT *WBT
COOLING
Maximum 32 23 43 26
Minimum 16 11 16 11
HEATING
Maximum 30 - 24 18
Minimum 16 - -5 -6
* DBT: Dry bulb temperature
* WBT: Wet bulb temperature
NOTICE: • This model is not suitable for 24 hours non-stopping operation in heating mode below -5°C.
When the outdoor temperature is below -5°C and you use this model out of above conditions, the
outdoor unit might be frozen up and stop operation for protection control.
PH005413 F567885 All.indb 5 2011-2-23 15:12:13

Panasonic CS-YE9MKE Specifications

General

Indoor unit type	Wall-mountable
Indoor units quantity	1
Indoor unit dimensions (WxDxH)	803 x 214 x 283 mm
Type	Air conditioner indoor unit
Hose length (max)	15 m
Remotely operated	Yes
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.4 l/h
Air conditioner functions	cooling, dehumidifying, heating, ventilating
Cooling capacity in watts (max)	2500 W
Heating capacity in watts (max)	3200 W
Airflow	12.5 m³/h
Power consumption (cooling) (max)	760 W
Power consumption (heating) (max)	880 W
