Panasonic CS-Z35UD3EAW - 7 Refrigeration Cycle Diagram; Cs-Z25 Ud3 Eaw Cu-Z25 Ubea Cs-Z35 Ud3 Eaw Cu-Z35 Ubea

25
7. Refrigeration Cycle Diagram
7.1 CS-Z25UD3EAW CU-Z25UBEA CS-Z35UD3EAW CU-Z35UBEA
INDOOR OUTDOOR
INTAKE
AIR
TEMP.
SENSOR
AIR
TEMP.
SENSOR
PIPE
TEMP.
SENSOR 1
PIPE
TEMP.
SENSOR 2
TANK
SENSOR
PIPE
TEMP.
SENSOR
LIQUID
SIDE
2-WAY
VALVE
3-WAY
VALVE
GAS
SIDE
COOLING
HEAT EXCHANGER
(EVAPORATOR)
HEATING
COMPRESSOR
4-WAYS VALVE
CONDENSER
MUFFLER
MUFFLER
STRAINERSTRAINER
EXPANSION
VALVE
