Panasonic CS-Z42XKEW Service Manual

14
Model
Indoor CS-Z20XKEW, CS-XZ20XKEW
Outdoor CU-Z20XKE
Compressor
Type Hermetic Motor / Rotary
Motor Type Brushless (6-poles)
Output Power W 550
Indoor Fan
Type Cross-flow fan
Material ASG30
Motor Type DC (8-pole)
Input Power W 47.1
Output Power W 30
Speed
QLo
Cool rpm 500
Heat rpm 510
Lo
Cool rpm 580
Heat rpm 620
Me
Cool rpm 720
Heat rpm 780
Hi
Cool rpm 860
Heat rpm 940
SHi
Cool rpm 920
Heat rpm 1000
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-pole)
Input Power W -
Output Power W 40
Speed Hi
Cool rpm 760
Heat rpm 740
Moisture Removal L/h (Pt/h) 1.3 (2.7)
Indoor Airflow
QLo
Cool m³/min (ft³/min) 5.94 (210)
Heat m³/min (ft³/min) 6.10 (215)
Lo
Cool m³/min (ft³/min) 7.23 (255)
Heat m³/min (ft³/min) 7.87 (278)
Me
Cool m³/min (ft³/min) 9.48 (335)
Heat m³/min (ft³/min) 10.44 (369)
Hi
Cool m³/min (ft³/min) 11.70 (415)
Heat m³/min (ft³/min) 13.00 (460)
SHi
Cool m³/min (ft³/min) 12.70 (449)
Heat m³/min (ft³/min) 13.98 (494)
Outdoor Airflow Hi
Cool m³/min (ft³/min) 27.4 (965)
Heat m³/min (ft³/min) 26.7 (945)
Refrigerant Cycle
Control Device Expansion Valve
Refrigerant Oil cm³ FW50S (270)
Refrigerant Type kg (oz) R32, 0.67 (23.7)
F-Gas
GWP 675
CO2eq (ton)
(Precharge Amount / Maximum Charged Amount)
0.45 / 0.50
