14.11 Indication Panel
LED POWER TIMER nanoe X
Color White White White White
Light ON Operation ON Timer Setting ON nanoe ON
Wireless LAN Mode
ON
Light OFF Operation OFF Timer Setting OFF nanoe OFF
Wireless LAN Mode
OFF
Note:
 If POWER LED is blinking, the possible operation of the unit are Hot Start, during Deice operation, operation
mode judgment, or ON timer sampling.
 If Timer LED is blinking, there is an abnormality operation occurs.
14.12 nanoe
TM
X Operation
 Generate nanoe
TM
X (water wrapped ion particle) to moisturize skin, provide deodorization & sterilization effect.
 nanoe
TM
X operation start condition
o During unit running at any operation mode, if nanoe
TM
X operation is activated, combination operation
(operation mode + nanoe
TM
X operation) starts.
o During unit is OFF, if nanoe
TM
X operation is activated, nanoe
TM
X individual operation starts.
 nanoe
TM
X operation stop condition
o When OFF/ON button is pressed to stop the operation.
o When nanoe
TM
X button is pressed.
o When OFF Timer activates.
 nanoe
TM
X operation pause condition
o When indoor fan stop (during deice, odor cut control, thermostat off, etc.). nanoe
TM
X operation resume after
indoor fan restarts.
o When indoor intake temperature ≥ 35°C and ≤ 5°C. nanoe
TM
X operation resume after indoor intake
temperature < 35°C or ≥ 5°C continuously for 6 minutes.
 Indoor fan control
o During any operation mode combines with nanoe
TM
X operation, fan speed follows respective operation
mode. However, nanoe
TM
X system enabled when fan speed ≥ 360 rpm to ensure proper negative ion
distribution, nanoe
TM
X system disabled when fan speed < 360 rpm.
o During nanoe
TM
X individual operation, fan speed follow remote control setting. Auto Fan Speed for
nanoe
TM
X individual operation is cooling medium fan. Powerful & Quiet is disabled during nanoe
TM
X.
 Airflow direction control
o During any operation mode combines with nanoe
TM
X operation, airflow direction follows respective operation
mode.
o During nanoe
TM
X individual operation, Air Swing follow remote control setting.
 Timer control
o When ON Timer activates when unit stops, previous operation resumes and restored last saved nanoe
TM
X
operation status.
o When ON Timer activates during any operation, no change on current operation.
o When OFF Timer activates during any operation, all operation stops and the latest nanoe
TM
X operation
status is saved.
 Indicator
o When nanoe
TM
X starts, nanoe
TM
X indicator ON.
 Remote control receiving sound
o Normal Operation  nanoe
TM
X Operation : Beep
o nanoe
TM
X Operation  Normal Operation : Beep
o Stop  nanoe
TM
X individual Operation : Beep
o nanoe
TM
X individual Operation  Stop : Long Beep
