Panasonic CT-27G7DF - A-Board Transistor Voltages; C-Board Transistor Voltages

- 26 -
Q2350
7.24
0.00
0.72
B
C
E
Q090
1.44
0.00
2.12
Q006
2.67
0.00
3.32
Q007
2.72
0.00
3.36
Q008
2.74
0.00
3.39
Q051
5.00
0.00
2.67
Q052
5.00
0.00
2.74
B
C
E
Q053
0.00
5.00
2.67
Q054
0.00
5.00
2.72
Q055
0.00
5.00
2.74
Q050
5.00
0.00
2.72
Q505
2.44
4.98
2.30
Q520
1.74
4.98
1.58
B
C
E
Q001
0.034
11.73
0.00
Q606
0.00
3.63
0.00
Q092
9.00
2.82
5.00
Q451
0.59
0.00
0.00
Q453
0.00
8.65
0.00
Q009
0.55
0.04
0.00
B
C
E
Q830
129.5
126.3
130.1
Q501
0.40
84.40
0.00
Q820
130.1
0.00
130.5
Q551
-0.12
-31.37
0.00
Q452
0.00
2.49
0.00
Q605
4.23
0.00
4.21
B
C
E
Q351
6.49
165.00
6.03
B
C
E
Q352
6.35
169.70
5.89
Q353
6.34
168.50
5.93
Q354
3.32
6.49
2.75
Q355
3.36
6.35
2.79
Q356
3.38
6.34
2.81
C-Board transistor voltages TNP2AA106AG
A-Board transistor voltagesTNP2AH040BH
A&C-Board Qs
