-6-
Receiver Feature Table
FEATURE / MODEL ALL MODELS
Chassis JP363
No. of channels 181
Menu language Eng/Span/Fr
Closed Caption X
V-Chip (USA/CANADA) X
75 Ω input X
Remote model number EUR501450
Picture tube M68LGL061X
Panablack tube X
Comb filter 2Dig
V/A norm V
MTS/SAP/DBX X
AI Sound X
Built-in audio power 1.5W x 2 (10%)
Number of speakers 2
A/V in (rear/front) 1(1/1)
S-VHS input (rear/front) 1/0
Headphone jack X
Dimensions mm
(WxDxH) in
665.2 x 545 x 594.8
26.2 x 21.5 x 23.4
Weight (kg/lbs) 35 / 77.2
Power source (V/Hz) 120 / 60
Anode voltage 29.25kV ± 1.25kV
Video input jack
1V
p-p
75Ω, phono jack
Audio input jack 500mV RMS 47kΩ
A-Board TNP2AH040 BH*
C-Board TNP2AA106 AG*
Table 1. Receiver Features
Specifications are subject to change without notice or obligation.
Dimensions and weights are approximate.
*Note:When ordering a replacement board assembly,
append an “S” next to the board number.
Example: to order the A-Board for CT-27G7DF, the
replacement board is
TNP2AH040BHS
.
