Panasonic CT-27G7DF - Chassis View

-8-
Chassis View
Figure 4. Chassis view
Figure 3. A-Board main
components and test points
(components within dotted
areas are located on
trace side)
Back A/V inputs
Back S-Video input
HPJ output
Front A/V inputs
