16.2.2. Replacement Parts List
<Model: CU-2E15CBPG / CU-2E18CBPG>
Ref. No. Part Name & Description Q’ty Part No. Remarks
CU-2E15CBPG CU-2E18CBPG
1 TERMINAL BOARD COMPLETE (3P) 1 CWA28K1045
←
←←
← ●
●●
●
2 TERMINAL BOARD COMPLETE (4P) 2 CWA28K1046
←
←←
← ●
●●
●
3 VALVE COIL 1 CWA43C2112 CWA43C2086
●
●●
●
4 EXPANSION VALVE COIL 2 CWA43C2086
←
←←
←
●
●●
●
5 THERMISTOR(OUTDOOR, COND TEMP) 1 CWA50C2088
←
←←
← ●
●●
●
6 THERMISTOR(PIPE A.B TEMP) 1 CWA50C2089
←
←←
← ●
●●
●
7 THERMISTOR(DISCHARGE TEMP) 1 CWA50C2090
←
←←
← ●
●●
●
8 THERMISTOR(COND EXIT TEMP) 1 CWA50C2097
←
←←
← ●
●●
●
9 LEAD WIRE COMPLETE (COMP) 1 CWA67C4539
←
←←
←
10 PC BOARD (MAIN) 1 CWA73C1353 CWA73C1354
●
●●
●
10-1 PC BOARD (POWER) 1 CWA742957
←
←←
←
●
●●
●
11 FAN MOTOR 1 CWA981072
←
←←
← ●
●●
●
12 4-WAY VALVE 1 CWB001017
←
←←
←
●
●●
●
13 3-WAY VALVE (1/4) 2 CWB011080
←
←←
← ●
●●
●
14 3-WAY VALVE (3/8) 2 CWB011081
←
←←
←
●
●●
●
15 DRYER 1 CWB101011
←
←←
← ●
●●
●
16 STRAINER 1 CWB111004
←
←←
←
17 CONDENSER 1 CWB32C1160
←
←←
←
18 CHASSIS COMPLETE 1 CWD50K2058
←
←←
←
19 FAN MOTOR BRACKET 1 CWD541021
←
←←
←
20 HOLDER 1 CWD791001
←
←←
←
21 CABINET SIDE PLATE 1 CWE04C1015
←
←←
←
22 HANDLE 1 CWE161001
←
←←
←
22-1 OPERATION INSTARUCTIONS 1 CWF563678
←
←←
←
22-2 INSTALLATION INSTARUCTIONS 1 CWF612315
←
←←
←
23 SOUND PLOOF MATERIAL 1 CWG302138
←
←←
←
24 SOUND PLOOF MATERIAL 1 CWG302139
←
←←
←
25 PROPELLER FAN 1 CWH03K1005
←
←←
←
26 CONTROL BOARD-1 1 CWH102135
←
←←
←
27 CONTROL BOARD-2 1 CWH102136
←
←←
←
28 CONTROL BOARD-3 1 CWH102164
←
←←
←
29 CONTROL BOARD COVER-1 1 CWH131116
←
←←
←
30 CONTROL BOARD COVER-2 1 CWH13C1073
←
←←
←
31 TERMINAL COVER 1 CWH17006
←
←←
←
32 HOLDER-SENSOR-1 1 CWH32074
←
←←
←
33 HOLDER-SENSOR-2 4 CWH32075
←
←←
←
34 HOLDER-SENSOR-3 2 CWH32138
←
←←
←
35 HOLDER-COUPLING 1 CWH351018
←
←←
←
36 ANTI-VABRATION BUSHING 1 CWH4601085
←
←←
←
37 BELT-1 1 CWH4605004
←
←←
←
38 BELT-2 2 CWH4605010
←
←←
←
39 CAP-1 2 CWH4611109
←
←←
←
40 CAP-2 2 CWH4611110
←
←←
←
41 ANTI-VIBRATION BUSHING (COMP) 3 CWH501022
←
←←
←
42 BUSHING 1 CWH511039
←
←←
←
43 CAP-3 4 CWH521027
←
←←
←
44 CAP-4 4 CWH52273
←
←←
←
45 NUT (COMP) 3 CWH56000
←
←←
←
46 NUT (CROSS-FLOW FAN) 1 CWH56053
←
←←
←
47 DRAIN ELBOW 1 CWH5850080K
←
←←
←
48 NUT (TARMINAL) 1 CWH7080300
←
←←
←
49 REACTOR 1 CWA421051
←
←←
←
50 COMPRESSOR 1 CWMB090001
←
←←
← ●
●●
●
51 PARTICULAR PIECE 1 CWMD910006X
←
←←
←
52 CABINET TOP PLATE 1 CWME03C0001
←
←←
←
53 CABINET SIDE PLATE 1 CWE041054
←
←←
←
54 CABINET FRONT PLATE 1 CWE06C1046
←
←←
←
55 SOUND PLOOF PLATE 1 CWH151032
←
←←
←
56 HOLDER SENSOR-4 1 CWMH320001
←
←←
←
57 TUBE ASSY-1 1 CWT022719
←
←←
←
58 TUBE ASSY COMPLETE (CAPILLARY) 1 CWT01C2528
←
←←
←
59 TUBE ASSY COMPLETE (EXPANSION VALVE) 1 CWT01C2499
←
←←
←
60 TUBE ASSY COMPLETE (EXPANSION VALVE) 1 CWT01C2500
←
←←
←
61 TUBE ASSY-2 1 CWT022734
←
←←
←
62 TUBE ASSY-3 1 CWT022510
←
←←
←
63 TUBE ASSY-4 1 CWT022511
←
←←
←
64 TUBE ASSY-5 1 CWT022515
←
←←
←
65 TUBE ASSY-6 1 CWT022516
←
←←
←
66 TUBE ASSY-7 1 CWT022647
←
←←
←
