16.3.2. Replacement Parts List
<Model: CU-3E23CBPG>
Ref. No. Part Name & Description Q’ty Part No. Remarks
1 SWING COMPRESSOR 1 CW1266081
●
●●
●
2 VIBRATION ISOLATOR 3 CW1289899
3 NUT WITH WASHER 3 CWH56062
4 TERMINAL COVER 1 CW1262647
5 RUBBER BUSH, LEAD WIRE 1 CWH51260
6 RETAINER, OVER-LOAD RELAY 1 CW380620
7 SOUND INSULATOR, COMP. (TOP) 1 CW1306910
9 SOUND INSULATOR, COMPRESSOR 1 CW1306934
10 SOUND INSULATOR, COMPRESSOR 1 CW1306941
12 CROSS-FIN CONDENSER ASS’Y 1 CW1305809
14 FOUR WAY VALVE 1 CW1305830
●
●●
●
16 DISCHARGE PIPE 1 CW1351802
17 MUFFLER (SUCTION LINE) 1 CW1170298
18 DISCHARGE PIPE 1 CW1351819
19 CONNECTING PIPE 1 CW1351826
20 CONNECTING PIPE 1 CW1351833
21 SOLENOID VALVE ASS’Y 1 CW1313545
●
●●
●
22 VIBRATION ABSORBER, REF. PIPING 1 CWH50085
23 RETAINER, VIBRATION ABSORBER 1 CW0219253
25 SET PLATE, STOP VALVE (1) 1 CW1364101
26 SET PLATE, STOP VALVE (2) 1 CW1306996
28 STOP VALVE ASS’Y (LIQUID LINE) 1 CW1305847
●
●●
●
30 BODY, MOTORIZED EXP. VALVE 3 CW1296385
●
●●
●
31 UNION JOINT 3 CW0603214
32 STRAINER (FOR REF.) 3 CW1318230
33 STRAINER (FOR REF.) 1 CW0085296
34 PUTTY 3 CW1307014
35 PUTTY 1 CW1313134
36 SOUND ABSORBING PUTTY 1 CW962621
37 FIXTURE, THERMISTOR 3 CW1303896
39 STOP VALVE ASS’Y (GAS LINE) 1 CW1305854
●
●●
●
41 UNION JOINT 3 CW257587
42 FITTING SPRING, THERMISTOR 4 CW380120
43 FIXTURE, UNION JOINT 1 CW1313141
44 ACCUMULATOR ASS’Y 1 CW1305885
45 CUSHION RUBBER, ACCUMULATOR 1 CW380116
46 PUTTY 1 CW0640338
47 FLARE NUT 3 CW0080347
48 BLIND CAP, FLARE NUT 3 CW1020937
49 FLARE NUT 3 CW1198474
50 BLIND CAP, FLARE NUT 3 CW1020920
51 CAP, STOP VALVE 1 CWH521017
52 CAP, STOP VALVE 1 CW0079936
53 FIXTURE, THERMISTOR 1 CW1107384
54 SUCTION LINE ASS’Y 1 CW1351927
55 PUTTY 1 CW1201589
56 SOUND ABSORBING PUTTY 1 CW1128538
57 SOUND ABSORBING PUTTY 1 CW0141521
58 FAN BLADE 1 CW1183821
59 LOCK NUT, FAN BLADE 1 CW847002
60 AIR DISCHARGE GRILLE 1 CW1314308
61 GUARD NET 1 CW1182385
63 SWITCH BOX 1 CW1307069
64 CUSHION RUBBER 1 CW1307076
65 PRINTED CIRCUIT ASS’Y 1 CW1364118
●
●●
●
66 FUSE 1 CW0509002
67 VARISTOR 1 CW0608055
●
●●
●
68 WIRE HARNESS ASS’Y 1 CW1307083
69 HEAT SINK 1 CW1289914
●
●●
●
70 TERMINAL BLOCK 1 CW1364125
●
●●
●
71 PRINTED CIRCUIT ASS’Y (INVERTER) 1 CW1290402
●
●●
●
72 THERMISTOR 1 CW1302622
●
●●
●
73 RECTIFING STACK 1 CW628953
74 POWER TRANSISTOR MODULE 1 CW1289921
●
●●
●
75 THERMISTOR ASS’Y 1 CW1302639
●
●●
●
79 REACTOR 1 CW1305955
80 WIRE HARNESS ASS’Y 1 CW1305962
81 COIL, SOLENOID VALVE ASS’Y 1 CW1364132
●
●●
●
82 COIL, SOLENOID VALVE 1 CW1296378
●
●●
●
84 DC FAN MOTOR 1 CW1307160
●
●●
●
