Panasonic CU-3C20BKP5G Service Manual

16 Replacement Parts List
<Model: CS-C7BKPG / CS-C9BKPG / CS-C12BKPG>
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-C7BKPG CS-C9BKPG CS-C12BKPG REMARKS
1 CHASSY COMPLETE 1 CWD50C1177
← ←
2 FAN MOTOR 1 CWA921060
← ←
0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1012
← ←
4 BEARING ASS’Y 1 CWH64K007
← ←
5 SCREW - CROSS FLOW FAN 1 CWH4580304
← ←
6 EVAPORATOR 1 CWB30C1143
←
CWB30C1124
7 FLARE NUT 1 CWH6002140(1/4”)
← ←
8 FLARE NUT 1 CWT25005 (3/8”)
←
CWT25007 (1/2”)
9 INTAKE AIR SENSOR HOLDER 1 CWH32142
← ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2101
← ←
11 VERTICAL VANE 12 CWE241068
← ←
12 CONNECTING BAR 2 CWE261024
← ←
13 AIR SWING MOTOR 1 CWA98260
← ←
0
14 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3977
← ←
15 CAP - DRAIN TRAY 1 CWH52C1001
← ←
16 HORIZONTAL VANE 1 CWE241070
← ←
17 PARTICULAR PIECE 1 CWD932162
← ←
18 CONTROL BOARD 1 CWH102103
← ←
19 TERMINAL BOARD COMPLETE 1 CWA28C2082
← ←
0
20 ELECTRONIC CONTROLLER - MAIN 1 CWA742779 CWA742780 CWA742781 0
21 LEAD WIRE - FAN MOTOR 1 CWA67C3729
← ←
22 ELECTRONIC CONTROLLER - RECEIVER 1 CWA73C1124
← ←
0
23 SENSOR COMPLETE 1 CWA50C608
← ←
0
24 CONTROL BOARD FRONT COVER 1 CWH131090
← ←
25 ELECTRONIC CONTROLLER - INDICATOR 1 CWE39C1042
← ←
0
26 LEAD WIRE - INDICATOR 1 CWA67C3637
← ←
27 INDICATOR HOLDER 1 CWD932163
← ←
28 CONTROL BOARD TOP COVER 1 CWH131091
← ←
29 REMOTE CONTROL COMPLETE 1 CWA75C2162
← ←
0
30 FRONT GRILLE COMPLETE 1 CWE11C2329
← ←
31 INTAKE GRILLE 1 CWE221036
← ←
32 CONTROL PANEL 1 CWE312114
← ←
33 DECORATION BASE (R) 1 CWE351067
← ←
34 DECORATION BASE (L) 1 CWE351068
← ←
35 GRILLE DOOR 1 CWE141033
← ←
36 AIR FILTER 2 CWD001047
← ←
37 SCREW - FRONT GRILLE 2 XTN4+16C
← ←
38 CAP - FRONT GRILLE 2 CWH521062
← ←
39 DRAIN HOSE 1 CWH85287
← ←
40 INSTALLATION PLATE 1 CWH36K1006
← ←
41 ANTI-VIBRATION BUSHING 1 - - CWH501023
42 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
← ←
43 AIR PURIFYING FILTER 1 CWMD00C0001
← ←
0
44 SOLAR DEODORIZING FILTER 1 CWMD00C0002
← ←
0
(Note)
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086).
•
“O” marked parts are recommended to be kept in stock.
70
CS-C9BKPG CU-2C14BKP5G / CS-C9BKPG CU-2C18BKP5G / CS-C9BKPG CU-3C20BKP5G / CS-C7BKPG CU-2C19BKP5G / CS-C12BKPG
