22 Replacement Parts List
<Model: CU-3C20BKP5G>
NO. DESCRIPTION & NAME Q’TY CU-3C20BKP5G REMARKS
1 CHASSY ASS’Y 1 CWD50K663A
2 COMPRESSOR 1 2PS193D2AA01 0
3 AIR GUIDER 1 CWD31094A
4 SOUND PROOF BOARD 1 CWH15071
5 FAN MOTOR BRACKET 1 CWD54179
6 CONDENSER 1 CWB32C1029
7 FAN MOTOR 1 CWA951179
8 PROPELLER FAN 1 CWH00023
9 COMPRESSOR 1 2PS134D2AA01
10 3-WAY VALVE (LIQUID SIDE) 2 CWB01385 0
11 3-WAY VALVE (GAS SIDE) 3 CWB01384 0
12 HOLDER COUPLING 1 CWH35127A
13 CAPILLARY TUBE 2 CWB15315
14 CAPILLARY TUBE 1 CWB15199
15 2-WAY VALVE 2 CWB02306
16 V - COIL COMPLETE 1 CWA43C516 0
17 CONTROL BOARD 1 CWH102151 0
18 TRANSFORMER 1 CWA40C192 0
19 ELECTRONIC CONTROLLER 1 CWA741165 0
20 CAPACITOR - COMPRESSOR 2 DS441256CPNA
(25µF, 440VAC)
0
21 CAPACITOR - FAN MOTOR 1 F0GAH305A002
(3.0µF, 450VAC)
0
22 TERMINAL BOARD 1 CWA4711012
23 TERMINAL BOARD 1 CWA28064
24 OVERLOAD PROTECTOR 1 CWA12336 0
25 OVERLOAD PROTECTOR 1 CWA12334 0
26 TERMINAL COVER - COMPRESSOR 2 CWH7070204
27 CABINET TOP PLATE 1 CWE03032A
28 3-WAY VALVE (LIQUID SIDE) 1 CWB01383 0
29 CONTROL BOARD COVER 1 CWH13322
30 CABINET FRONT PANEL 1 CWE06C111A
31 CABINET SIDE PLATE 1 CWE04131A
32 FAN GUARD 1 CWD04183
33 HANDLE 1 CWE16037C
34 CAPILLARY TUBE 1 CWB15474
35 ANTI - VIBRATION BUSHING 6 CWH50049
36 SOUND PROOF MATERIAL 2 CWG30267
37 HOLDER - OVERLOAD PROTECTOR 2 CWH7041200
38 STRAINER 1 CWB11002
39 STRAINER 1 CWB11004
40 OPERATING INSTRUCTION 1 CWF563436
41 INSTALLATION INSTRUCTION 1 CWF612239
42 NUT - COMPRESSOR 6 CWH56000
43 HOLDER CAPACITOR 2 CWH30078
44 NUT - TERMINAL COVER 2 CWH7080300
45 TERMINAL BOARD ASS’Y 1 CWA28K234
46 HOLDER CAPACITOR - FAN 1 CWH301005
47 INSTALLATION INSTRUCTION 1 CWF612242
48 INSTALLATION INSTRUCTION 1 CWF612243
(Note)
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086).
•
“O” marked parts are recommended to be kept in stock.
