Panasonic CU-3C20BKP5G Service Manual

25 Electronic Parts List
<Electronic Controller Part No.: CWA742779, CWA742780 & CWA742781>
SYMBOL DESCRIPTION & NAME PART NO.
BZ101 SOUND GENERATOR A48040
C-FM SH CAPACITOR A31698
D08, D10, D11 DIODE B0ACCK000005 (CWA742779 & CWA742780 only)
DB01 DIODE A54CS1VB20E
FUSE FUSE XBA2C20TR0
FUSE HOLDER FUSE HOLDER XCSCW012
IC01 INTEGRATED CIRCUIT A52D0022GB34
IC02 INTEGRATED CIRCUIT C3EBDG000021
IC03 INTEGRATED CIRCUIT A52C040
IC04 INTEGRATED CIRCUIT A52C114
IC05 INTEGRATED CIRCUIT A52A2003GR2
L01 V-COIL A431036
PC01 PHOTO COUPLER A52LP620-G4
Q01, Q02, Q03 TRANSISTOR B1GBCFGH0001
Q04, Q05, Q06 TRANSISTOR A55C2412KTX
RY-PWR ELECTRO MAGNETIC RELAY K6B1AGA00077
SSR01 TYRISTOR A56G3MC202PL
T01 TRANSFORMER A401030
X01 RESONATOR A45CSTS409MG
ZD1 DIODE B0BC7R400003
ZNR01, ZNR03 DIODE ERZVEAV511
(Note)
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086)
