(NOTE)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
REF. NO. PART NAME & DESCRIPTION QTY. CU-2E15LBE CU-2E18LBE REMARKS
1 CHASSY ASSY 1 CWD50K2058 ←
2 FAN MOTOR BRACKET 1 CWD541089 ←
3 FAN MOTOR AC 50W SINGLE 1 CWA981072 ← O
4 PROPELLER FAN 1 CWH03K1013 ←
5 NUT - PROPELLER FAN 1 CWH561034J ←
6 COMPRESSOR 1 5CS102XFC ←
7 ANTI - VIBRATION BUSHING 3 CWH501022 ←
8 NUT - COMPRESSOR 3 CWH56000J ←
9 SOUND PROOF MATERIAL 1 CWG302138 ←
10 SOUND PROOF MATERIAL 1 CWG302139 ←
11 SOUND PROOF MATERIAL 1 CWG302404 —
12 SOUND PROOF MATERIAL 1 CWG302405 —
13 CONDENSER COMPLETE 1 CWB32C1816 ←
14 TUBE ASS’Y (CAPPILLARY TUBE) 1 CWT01C4066 ←
15 RECEIVER 2 CWB14013 ←
16 TUBE ASS'Y (CAPI TUBE MUFLER EXP VALVE) 1 CWT01C2499 ←
17 TUBE ASS'Y (CAPI TUBE MUFLER EXP VALVE) 1 CWT01C2500 ←
18 DISCHARGE MUFFLER 2 CWB121002 ←
19 EXPANTION VALVE 2 CWB051008J ←
20 4-WAYS VALVE 1 CWB001027J ←
21 STRAINER 1 CWB111004 ←
22 DRYER 1 CWB101016J ←
25 V-COIL COMPLETE 2 CWA43C2086J ← O
26 V-COIL COMPLETE 1 CWA43C2212 ← O
27 SOUND-PROOF BOARD 1 CWH151032 ←
28 HOLDER-SENSOR 1 CWMH320001 ←
29 SENSOR-COMPLETE 1 CWA50C2088 ← O
30 HOLDER-SENSOR 3 CWH32138 ←
31 SENSOR-COMPLETE 1 CWA50C2089 ← O
32 SENSOR-COMPLETE 1 CWA50C2090 ← O
33 HOLDER-SENSOR 2 CWH32074 ←
34 SENSOR-COMPLETE 1 CWA50C2097 ← O
35 NORMAL-MODE LINE CHOKE COILS 1 G0A193M00001 ← O
36 ELECTRONIC CONTROLLER 1 CWA73C4521R CWA73C4522R O
37 TERMINAL BOARD ASS'Y 1 CWA28K1162 ←
38 TERMINAL BOARD ASS'Y 2 CWA28K1161 ←
39 FUSE 1 XBA2C50TR0 ←
40 CONTROL BOARD COVER 1 CWH131116 ←
41 TERMINAL COVER 2 CWH171001 ←
42 RUBBER GASKET 2 CWH7070603 ←
43 3-WAY VALVE 2 CWB011418 ←
44 3-WAY VALVE 2 CWB011081J ←
45 HOLDER COUPLING 1 CWH351018 ←
46 NUT - TERMINAL COVER 2 CWH7080300J ←
47 CABINET TOP PLATE 1 CWE031014A ←
48 CABINET FRONT PLATE CO. 1 CWE06C1136 ←
49 CABINET SIDE PLATE COMP 1 CWE04C1085 ←
50 CABINET SIDE PLATE 1 CWE041074A
←
51 CONTROL BOARD COVER COMPLETE 1 CWH13C1073 ←
52 HANDLE 1 CWE161010 ←
53 INSTALLATION INSTRUCTION 1 CWF613180 ←
54 INSTALLATION INSTRUCTION 1 CWF613181 ←
To Next Page
