 Multi Split Combination Possibility:
o A single outdoor unit enables air conditioning of up to four separate rooms for CU-4Z80TBE.
OUTDOOR UNIT
CONNECTABLE INDOOR UNIT
CU-4Z80TBE
ROOM A B C D
1.6kW
CS-MZ16TKE
CS-MTZ16TKE
● ● ● ●
2.0kW
CS-Z20TKEW
CS-XZ20TKEW
CS-TZ20TKEW
CS-TE20TKEW
●
● ● ●
2.5kW
CS-Z25TKEW
CS-XZ25TKEW
CS-TZ25TKEW
CS-TE25TKEW
CS-E9PD3EA
CS-E9PB4EA
●
● ● ●
3.5kW
CS-Z35TKEW
CS-XZ35TKEW
CS-TZ35TKEW
CS-TE35TKEW
CS-E12QD3EAW
CS-E12PB4EA
●
● ● ●
4.2kW
CS-Z42TKEW
CS-TZ42TKEW
CS-TE42TKEW
● ● ● -
5.0kW
CS-Z50TKEW
CS-XZ50TKEW
CS-TZ50TKEW
CS-TE50TKEW
CS-E18RD3EAW
CS-E18RB4EAW
●
● - -
6.0kW
CS-TZ60TKEW
CS-TE60TKEW
CS-E21RB4EAW
● ● - -
Wall
7.0kW
CS-Z71TKEW
CS-TZ71TKEW
● ● - -
Capacity range of connectable indoor units 4.5kW ~ 14.7kW
1-room maximum pipe length (m) 25
Allowable elevation (m) 15
Total allowable pipe length (m) 70
Total pipe length for maximum
chargeless length (m)
45
Pipe length
Additional gas amount over
chargeless length (g/m)
20
Note: “•” : Available
Remarks for CU-4Z80TBE
1. At least two indoor unit must be connected.
2. The total nominal cooling capacity of indoor unit that will be connected to outdoor unit must be within connectable capacity range of indoor
unit. (as shown in the table above)
Example: The indoor units’ combination below is possible to CU-4Z80TBE.
(Total nominal capacity of indoor units is between 4.5kW to 14.7kW)
1) Two CS-Z25TKEW only. (Total nominal cooling capacity is 5.0kW)
2) Three CS-Z35TKEW only. (Total nominal cooling capacity is 10.5kW)
