8
2.5. Group Control Equipment
Wired
Remote
Control
Group control by one remote control
• All air conditioner units are controlled
as a whole by remote control.
• All indoor units operate in the same
mode.
• A maximum of 16 units can be con-
nected together (sequential starting)
[Remote side]
• Optional wired remote
control CZ-RD513C
[Local side]
Not needed
Twin remote control separate control
• Each indoor unit can be operated by
either one of the two remote control.
• Apart from timer setting time, displays
for two remote control are identical.
• Last button pressed has priority (main
or slave is set at remote control unit).
[Remote side]
• Optional wired remote
control
[Local side]
• Optional wired remote
control CZ-RD513C
Common
Control
Common control / group
• Operation is possible using either
wired or wireless remote control unit.
• Last button pressed has priority.
• Optional wired remote
control and wireless
remote control
Wired CZ-RD513C
Wireless CZ-RL013T
