190
SAFETY
REF
NO.
PART NAME & DESCRIPTION QTY. CS-E7PKR CS-E9PKR CS-E12PKR CS-E15PKR REMARK
1 CHASSIS COMPLETE 1 CWD50C1653 ← ← ←
2 FAN MOTOR 1 ARW7628AC ← ← ARW7627AC O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1076 ← ← ←
4 BEARING ASS’Y 1 CWH64K1006 ← ← ←
5 SCREW - CROSS FLOW FAN 1 CWH551146 ← ← ←
6 ION GENERATOR 1 CWH94C0043 ← ← ←
7 EVAPORATOR 1 CWB30C4225 CWB30C4210 CWB30C4445 CWB30C4593
8 FLARE NUT (LIQUID) 1 CWT251030 ← ← ←
9 FLARE NUT (GAS) 1 CWT251031 ← CWT251073 ←
10 HOLDER SENSOR 1 CWH32143 ← ← ←
11 CONTROL BOARD CASING 1 CWH102449 ← ← ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2357 ← ← ← O
13 ELECTRONIC CONTROLLER - MAIN 1 CWA73C7997 CWA73C7998 CWA73C7999 CWA73C7967 O
14 ELECTRONIC CONTROLLER - HVU 1 N0GE1F000002 ← ← ← O
15
ELECTRONIC CO. - INDICATOR &
RECEIVER
1 CWA746634 ← ← ← O
16 SENSOR COMPLETE 1 CWA50C2122 ← ← ← O
17 SENSOR COMPLETE (ECO) 1 CWA50C3192 ← ← ← O
18
ELECTRONIC CONTROLLER
(ECO SENSOR-L)
1 CWA745791 ← ← ←
19
ELECTRONIC CONTROLLER
(ECO SENSOR-R)
1 CWA746206 ← ← ←
20
ELECTRONIC CONTROLLER
(COMPARATOR)
1 CWA746653 ← ← ←
21 LEAD WIRE - PCB ECO 1 CWA68C1620 ← ← ←
22
CONTROL BOARD CASING FOR
PCB ECO
1 CWD933407 ← ← ←
23 CONTROL BOARD TOP COVER 1 CWH131467 ← ← ←
24 INDICATOR HOLDER 1 CWD933406 ← ← ←
25 CONTROL BOARD FRONT COVER 1 CWH13C1247 ← ← ←
26 DISCHARGE GRILLE COMPLETE 1 CWE20C3235 ← ← ←
27 BACK COVER CHASSIS 1 CWD933233 ← ← ←
28 FULCRUM 1 CWH621131 ← ← ←
29 VERTICAL VANE 8 CWE241374 ← ← ←
30 CONNECTING BAR 1 CWE261250 ← ← ←
31 CONNECTING BAR 1 CWE261256 ← ← ←
32 AIR SWING MOTOR 1 CWA98K1016 ← ← ← O
33 AIR SWING MOTOR 1 CWA981264 ← ← ← O
34 CAP - DRAIN TRAY 1 CWH521096 ← ← ←
35 HORIZONTAL VANE 1 CWE24C1385 ← ← ←
36 REMOTE CONTROL COMPLETE 1 CWA75C4406 ← ← ← O
37 FRONT GRILLE COMPLETE 1 CWE11C5445 ← ← ← O
38 INTAKE GRILLE COMPLETE 1 CWE22C1723 ← ← ←
39 GRILLE DOOR 1 CWE14C1090 ← ← ←
40 AIR FILTER 2 CWD001279 ← ← ← O
41 SCREW - FRONT GRILLE 3 XTT4+16CFJ ← ← ←
42 CAP - FRONT GRILLE 2 CWH521227 ← ← ←
43 DRAIN HOSE 1 CWH851173 ← ← ←
44 INSTALLATION PLATE 1 CWH361134 ← ← ←
45
BAG COMPLETE - INSTALLATION
SCREW
1 CWH82C1705 ← ← ←
50 BAG 1 CWG861497 ← ← ←
51 SHOCK ABSORBER (LEFT) 1 CWG713386 ← ← ←
52 SHOCK ABSORBER (RIGHT) 1 CWG713387 ← ← ←
53 C.C. CASE 1 CWG567355
(Note)
 All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488).
“O” marked parts are recommended to be kept in stock.
