Panasonic CU-E24PKR - Page 194

194
SAFETY
REF.
NO.
DESCRIPTION & NAME QTY. CU-E7PKR CU-E9PKR CU-E12PKR REMARK
1 BASE PAN ASS'Y 1 CWD52K1277 ← ←
2 SOUND PROOF MATERIAL 1 CWG302314 CWG302719 ←
3 FAN MOTOR BRACKET 1 CWD541167 ← ←
4 SCREW - FAN MOTOR BRACKET 2 CWH551217 ← ←
5 FAN MOTOR 1 ARS6411AC ← ← O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J ← ←
7 PROPELLER FAN ASS’Y 1 CWH03K1066 ← ←
8 NUT - PROPELLER FAN 1 CWH56053J ← ←
9 COMPRESSOR 1 5RS092XCD21 5RS102XNA21 ← O
10 ANTI - VIBRATION BUSHING 3 CWH50077 ← ←
11 NUT - COMPRESSOR MOUNT 3 CWH56000J ← ←
12 CONDENSER COMPLETE 1 CWB32C3637 CWB32C3218 ←
13 CAPILLARY TUBE ASSY 1 CWB15K1398 CWT01C6326 CWT01C6325
14 DISCHARGE MUFFLER 1 CWB121010 ← ←
15 HOLDER - COUPLING 1 CWH351233 ← ←
16 2 WAYS VALVE (LIQUID) 1 CWB021564 CWB021400 ← O
17 3 WAYS VALVE (GAS) 1 CWB011581 CWB011374 CWB011367 O
19 REACTOR 1 G0C193J00002 ← ← O
20 TERMINAL COVER 1 CWH171039A ← ←
21 NUT - TERMINAL COVER 1 CWH7080300J ← ←
22 SOUND PROOF BOARD 1 CWH151274 ← ←
23A SOUND PROOF MATERIAL 1 CWG302315 CWG302726 ←
23B SOUND PROOF MATERIAL 1 CWG302316 CWG302701 ←
24 SENSOR CO.-COMP TEMP 1 CWA50C2830 ← ← O
26 ELECTRONIC CONTROLLER - MAIN 1 CWA73C8000R CWA73C8001R CWA73C8002R O
27 TERMINAL BOARD ASSY 1 CWA28K1110J ← ← O
28 CABINET SIDE PLATE (R) 1 CWE04C1296 ← ←
29 SENSOR CO.-AIR AND COND TEMP 1 CWA50C2825 ← ← O
30 CABINET SIDE PLATE (L) 1 CWE041580A CWE041579A ←
31 CABINET FRONT PLATE ASSY 1 CWE06C1360 ← ←
32 CABINET TOP PLATE 1 CWE031148A ← ←
34 CONTROL BOARD COVER (R) 1 CWH13C1253 ← ←
38 4 WAYS VALVE 1 CWB001037J ← ← O
39 V-COIL COMPLETE 1 CWA43C2447 ← ← O
40 WIRE NET 1 CWD041166A ← ←
41 ACCESSORY CO. (DRAIN ELBOW) 1 CWG87C900 ← ←
42 ELECTRONIC CONT.- DEMAND CONTROL 1 CWA747605 ← ← O
43 CRANKCASE HEATER 1 CWA341044 ← ← O
46 OPERATING INSTRUCTION 1 CWF569361 ← ←
47 INSTALLATION INSTRUCTION 1 CWF615541 ← ←
48 CONTROL BOARD COVER (TOP) 1 CWH131473 ← ←
49 STRAINER 1 CWB11025 - ←
50 HOLDER SENSOR 1 CWH32143 ← ←
51 BAG 1 CWG861078 ← ←
52 BASE BOARD-COMPLETE 1 CWG62C1144 ← ←
53 SHOCK ABSORBER (RIGHT) 1 CWG713415 ← ←
54 SHOCK ABSORBER (LEFT) 1 CWG713416 ← ←
55 C.C. CASE 1 CWG566848 ← ←
(Note)
 All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488).
“O” marked parts are recommended to be kept in stock.
