NO. PART DESCRIPTION QTY. CU-L34DBE5 CU-L43DBE5
1 BASE PAN ASS’Y 1 CWD52K1110
←
←←
←
2 COMPRESSOR 1 5JD420XAA22
←
←←
←
3 ANTI-VIBRATION BUSHING 3 CWH50055
←
←←
←
4 NUT FOR COMP. MOUNT. 3 CWH4582065
←
←←
←
4a PACKING 3 CWB811017
←
←←
←
5 CRANKCASE HEATER 1 CWA341013
←
←←
←
6 CONDENSER COMPLETE 1 CWB32C1508
←
←←
←
7 TUBE ASS’Y(PRESSURE SWITCH) 1 CWT023392
←
←←
←
8 DISCHARGE MUFFLER 1 CWB121014
←
←←
←
9 HIGH PRESSURE SWITCH 1 CWA101007
←
←←
←
10 3-WAYS VALVE (GAS) 1 CWB011251
←
←←
←
11 4-WAYS VALVE 1 CWB001046
←
←←
←
12 3-WAYS VALVE (LIQUID) 1 CWB011292
←
←←
←
13 STRAINER 2 CWB111032
←
←←
←
15 PIPE HOLDER RUBBER 5 CWG251021
←
←←
←
17 HOLDER-SERVICE VALVE 1 CWD911425
←
←←
←
19 ACCUMULATOR ASS’Y 1 CWB131026A
←
←←
←
20 SOUND PROOF MATERIAL-COMP 1 CWG302265
←
←←
←
21 SOUND PROOF MATERIAL 1 CWG302266
←
←←
←
22 SOUND-PROOF BOARD ASS’Y 1 CWH15K1019
←
←←
←
23 V-COIL COMPLETE 1 CWA43C2169
←
←←
←
24 V-COIL COMPLETE 1 CWA43C2177
←
←←
←
25 PIPE SENSOR (DISCHARGE) 1 CWA50C2229
←
←←
←
26 PIPE SENSOR (COIL) 1 CWA50C2230
←
←←
←
27 PIPING SENSOR 1 CWA50C2231
←
←←
←
28 CABINET REAR PLATE 1 CWE02C1014
←
←←
←
29 CONTROL BOARD ASS’Y 1 CWH10K1049
←
←←
←
31 TERMINAL BOARD ASS’Y 1 CWA28K1107
←
←←
←
32 TERMINAL BOARD ASS’Y 1 CWA28K1076
←
←←
←
33 CAPACITOR-FAN MOTOR (3/460) 2 DS461305QP-A
←
←←
←
34 ELECTRONIC CONTROLLER (P. SUPPLY) 1 CWA743568 CWA743478
36 ELECTRONIC CONTROLLER (DISPLAY) 1 CWA743566
←
←←
←
38 ELECTRONIC CONTROLLER (NOISE FILTER) 1 CWA743567
←
←←
←
44 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1682R CWA73C1683R
46 REACTOR 2 CWA421079
←
←←
←
47 PARTICULAR PLATE COVER ASS’Y 1 CWD90K1023
←
←←
←
48 TERMINAL COVER 1 CWH171035
←
←←
←
49 NUT FOR TERMINAL COVER 1 CWH7080300
←
←←
←
50 BRACKET FAN MOTOR 1 CWD54K1014
←
←←
←
50a SCREW-BRACKET FAN MOTOR 4 CWH551040
←
←←
←
54 FAN MOTOR 2 CWA951363
←
←←
←
54a SCREW-FAN MOTOR 8 CWH551040
←
←←
←
55 PROPELLER FAN 2 CWH001021
←
←←
←
56 NUT for PROPELLER FAN 2 CWH561038
←
←←
←
57 CABINET FRONT PLATE 1 CWE061098A
←
←←
←
58 DISCHARGE GRILLE 2 CWE201073
←
←←
←
59 CABINET SIDE PLATE 1 CWE04K1023A
←
←←
←
60 WIRE NET 1 CWD041068A
←
←←
←
61 CABINET TOP PLATE COMPLETE 1 CWE03C1021
←
←←
←
62 ACCESSORY COMPLETE 1 CWH82C1105
←
←←
←
63 BAG-COMPLETE (L-TUBE) 1 CWG87C2030
←
←←
←
64 PIPE COVER (FRONT) 1 CWD601074A
←
←←
←
65 PIPE COVER (BACK) 1 CWD601075A
←
←←
←
66 CABINET FRONT PLATE COMPLETE 1 CWE06C1091
←
←←
←
67 HANDLE 2 CWE161008
←
←←
←
68 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1196
←
←←
←
69 MAGNETIC SWITCH 1 CWA001023
←
←←
←
100 LEADWIRE-COMPRESSOR 1 CWA67C5267
←
←←
←
101 SPRING FOR SENSOR 4 CWH711010
←
←←
←
102 4-WAYS VALVE COMPLETE 1 CWB00C1022
←
←←
←
103 CONDENSER SIDE PLATE 1 CWD932477
←
←←
←
INSTALLATION INSTRUCTION 1 CWF612612
←
←←
←
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
96
CS-F34DB4E5 CU-L34DBE5 / CS-F43DB4E5 CU-L43DBE5
