Panasonic CY-PAD1003N

Ref. No. Part No. Part Name & Description Remarks
RG1 01-11030-63 10kΩ 1/8W T
RP1 01-13320-63 3.3kΩ 1/8W T
RP2 01-13320-63 3.3kΩ 1/8W T
RP3 01-13320-63 3.3kΩ 1/8W T
RP4 01-13320-63 3.3kΩ 1/8W T
RP12 01-54520-85 4.53kΩ T
RP13 01-12050-63 2MΩ 1/8W T
RP14 01-11530-63 1.5MΩ 1/8W T
RP15 01-52230-61 22kΩ 1/8W T
RP16 01-51530-85 15kΩ T
RP17 01-53620-62 3.6kΩ 1/8W T
RP18 01-15630-63 56kΩ 1/8W T
RP19 01-13020-63 3kΩ 1/8W T
RP20 01-11030-63 10kΩ 1/8W T
RP21 01-11050-63 1MΩ 1/8W T
RP22 01-16810-63 680Ω 1/8W T
RP23 01-11000-63 10Ω 1/8W T
RP24 01-11020-63 1kΩ 1/8W T
RP25 01-11020-63 1kΩ 1/8W T
RP26 01-11020-43 1kΩ 1/4W T
RP27 01-11020-43 1kΩ 1/4W T
RP28 01-12200-43 22Ω 1/4W T
RP29 01-12200-43 22Ω 1/4W T
RP30 01-12200-43 22Ω 1/4W T
RP31 01-12200-43 22Ω 1/4W T
RP32 01-12200-43 22Ω 1/4W T
RP33 01-12200-43 22Ω 1/4W T
RP33A 01-12200-22 22Ω 1/2W T
RP33B 01-12200-22 22Ω 1/2W T
RP34 01-11001-22 1Ω 1/2W T
RP34A 01-11001-22 1Ω 1/2W T
RP34B 01-11020-63 1kΩ 1/8W T
RP35 01-11020-63 1kΩ 1/8W T
RP36 01-11030-63 10kΩ 1/8W T
RP37 01-11040-63 100kΩ 1/8W T
RP38 01-14720-63 4.7kΩ 1/8W T
RP39 01-11030-63 10kΩ 1/8W T
RP40 01-11000-43 10Ω 1/4W T
RP43 01-11000-43 10Ω 1/4W T
RP44 01-14720-11 4.7kΩ 1W T
RR1 01-11040-63 100kΩ 1/8W T
RR2 01-11020-63 1kΩ 1/8W T
RV1 01-51530-64 15.6kΩ 1/8W T
RV2 01-53030-62 30kΩ 1/8W T
THERMISTOR
RT 13-00215-00 Thermistor T
VARIABLE RESISTERs
VR1 15-22030-07 VR T
VR2 15-22030-07 VR T
VR3 15-25030-06 VR T
SWITCHs
S1 18-00886-00 2P2T Switch T
SW1 18-00886-00 2P2T Switch T
SW2 18-00886-00 2P2T Switch T
TRANSFOMER
TR1 20-00217-00 Transfomer T
CONNECTORs
CON1 30-00281-00 2Pin Terminal T
CON2 30-00115-02 2Pin Connector T
T1 32-00637-02 3P Terminal T
T2 32-00638-02 4P Terminal T
J1 30-00282-00 2Pin Connector T
J2 30-00283-00 3Pin Connector T
J3 30-00283-00 3Pin Connector T
Ref. No. Part No. Part Name & Description Remarks
J4 30-00284-00 5Pin Connector T
COILs
L3 20-00219-00 100uH Coil T
L4 20-00219-00 100uH Coil T
L5 20-00219-00 100uH Coil T
RELAY
RL1 21-00203-00 Relay T
FUSEs
F1 71-00418-00 25A Fuse T
F2 71-00418-00 25A Fuse T
F3 71-00418-00 25A Fuse T
INDUCTORs
B1 20-00211-00 Inductor T
B2 20-00211-00 Inductor T
B3 20-00211-00 Inductor T
B4 20-00211-00 Inductor T
L1 20-00221-00 Inductor T
L2 20-00220-00 Inductor T
LP1 20-00210-00 Inductor T
OTHER
RCA 32-00678-00 4Pin RCA Jack T
[11-05A17-32-C] Servo Block
IC
U1 07-00072-85 IC T
CAPACITORs
C1 02-21001-86 10µF 25WV T
C4 03-24740-85 0.47µF 50WV T
C6 02-21001-86 10µF 25WV T
C7 02-22201-85 22µF 25WV T
C8 02-22201-85 22µF 25WV T
C10 03-24710-85 470PF 50WV T
C12 03-24710-85 470PF 50WV T
CA1 02-22201-85 22µF 25WV T
CA2 03-21040-85 0.1µF 50WV T
CA3 02-22201-85 22µF 25WV T
CA4 03-21040-85 0.1µF 50WV T
RESISTERs
R1 01-51230-85 12kΩ T
R2 01-51230-85 12kΩ T
R3 01-51030-85 10kΩ T
R4 01-51620-84 1.6kΩ T
R5 01-54820-84 6.8kΩ T
R6 01-54330-85 43kΩ T
R7 01-54330-85 43kΩ T
R8 01-51020-85 1kΩ T
R9 01-54710-84 470Ω T
R10 01-51020-85 1kΩ T
R11 01-51020-85 1kΩ T
R13 01-51820-84 1.8kΩ T
R14 01-51820-84 1.8kΩ T
VARIABLE RESISTER
VR3 13-00220-85 VR T
CONNECTOR
6
CY-PAD1003N
