Panasonic CY-PAD1003N

Ref. No. Part No. Part Name & Description Remarks
CON1 30-00242-00 8P Connector T
[11-05A16-34-C] Driver Block
IC´s AND TRANSISTORs
U1 07-04051-85 IC T
U2 07-70004-85 IC T
U4 07-70008-85 IC T
U6 07-02011-85 IC T
U10 07-07809-85 IC T
U13 07-07805-85 IC T
Q1 08-05401-85 Transistor T
Q9 08-03904-85 Transistor T
Q17 08-01260-85 Transistor T
Q18 08-01898-85 Transistor T
DIODEs
D1 09-14148-85 Diode T
D2 09-14148-85 Diode T
D6 09-00014-85 Diode T
D7 09-00014-85 Diode T
D14 09-40120-85 Diode T
D19 09-20056-85 Zener Diode T
D20 09-14148-85 Diode T
D26 09-00014-85 Diode T
Z5 09-00240-85 Zener Diode T
Z6 09-20056-85 Zener Diode T
CAPACITORs
C1 03-22210-85 220PF 100WV T
C3 02-21001-86 10µF 25WV T
C8 03-21040-85 0.1µF 50WV T
C9 03-21050-85 1µF 16WV T
C17 03-21020-85 1000PF 100WV T
C18 03-21020-85 1000PF 100WV T
C23 03-23340-85 0.33µF 25WV T
C26 03-21040-86 0.1µF 100WV T
C29 02-21001-86 10µF 25WV T
C42 02-21001-86 10µF 25WV T
C44 03-21050-86 1µF 16WV T
C46 02-21001-86 10µF 25WV T
C47 02-21001-86 10µF 25WV T
C48 02-24701-85 47µF 35WV T
C53 03-21030-85 0.01µF 50WV T
C57 03-21040-85 0.1µF 50WV T
C60 02-21001-86 10µF 25WV T
C61 02-24701-86 47µF 25WV T
CA1 03-24740-03 0.47µF 100WV T
CA2 03-22240-05 0.22µF 100WV T
RESISTERs
R1 01-54730-83 47kΩ T
R3 01-51020-87 1kΩ T
R4 01-51020-85 1kΩ T
R8 01-53340-85 330kΩ T
R10 01-55620-85 5.6kΩ T
R11 01-51030-85 10kΩ T
R12 01-54730-84 47kΩ T
R13 01-51030-85 10kΩ T
R14 01-54730-84 47kΩ T
R17 01-51010-85 100Ω T
R21 13-00221-85 10kΩ T
R23 01-51010-85 100Ω T
R26 13-00220-85 1kΩ T
R31 01-52200-86 22Ω T
R33 01-51030-87 10kΩ T
R34 01-51030-87 10kΩ T
R41 01-51040-85 100kΩ T
R44 01-56820-84 6.8kΩ T
R47 01-59100-84 9.1kΩ T
Ref. No. Part No. Part Name & Description Remarks
R49 01-54700-85 4.7kΩ T
R50 01-52200-86 22Ω T
R68 01-52230-86 22kΩ T
R69 01-52230-86 22kΩ T
R72 01-53320-83 3.3kΩ T
R73 01-53320-83 3.3kΩ T
R74 01-51030-87 10kΩ T
R82 01-51030-85 10kΩ T
CONNECTORs
CON1 30-00280-00 5Pin Connector T
J1 30-00378-00 2Pin Connector T
Q5 30-00279-00 3Pin Connector T
Q6 30-00279-00 3Pin Connector T
[11-C000080-01] LED Block
LED´s
LED1 19-00328-00 LED T
LED2 19-00328-00 LED T
LED3 19-00328-00 LED T
LED4 19-00328-00 LED T
LED5 19-00328-00 LED T
LED6 19-00328-00 LED T
LED7 19-00328-00 LED T
LED8 19-00328-00 LED T
RESISTERs
R1 01-12210-85 220Ω T
R2 01-12210-85 220Ω T
R3 01-12210-85 220Ω T
R4 01-12210-85 220Ω T
RJ1 01-10000-95 0Ω 1/4W T
RJ2 01-10000-95 0Ω 1/4W T
Accessories
PRINTING
80-P4003-0N Operating Instructions T
Installation Hardware
(For Installation)
ST-RP450-20 Tapping Screw (5*20) T
YH-00018-00 Plain Washer (5*) T
YH-00016-01 Allen Wrench T
YH-00020-00 Spacer T
ST-RP450-40 Tapping Screw (5*40) T
(For Wiring)
35-00124-00 Speaker Input Connector T
76-00408-00 Terminal Cover for Short-Circuit
Prevention
T
Mechanical Parts
MISCELLANEOUS
1 71-00485-00 Bottom Panel T
2 78-00444-00 Gasket Bottom T
3 78-00410-00 Gasket Switch T
4 71-00711-00 Side Panel Right T
5 76-00411-00 VR Cap T
6 73-00159-00 Bracket 1VR T
7 11-00672-00 Main PCB w/Component T/RTL
8 78-00441-00 Mica Sheet T
9 74-00179-00 Bracket U Form T
10 11-00665-00 LED PCB w/Component T/RTL
11 76-00412-00 Display Lens Sheet T
12 76-00413-00 Display Lens T
13 77-00363-00 Heatsink T
14 76-00429-00 Display Cover T
7
CY-PAD1003N
