Page #10 background image
1-128
1
Simultaneous (Twin) -Type
1-1. Unit Specifi cations
PE1
6. 4-Way Cassette 60×60 Type S-36PY2E5A×2 / U-71PE1E5A
INDOOR MODEL S-36PY2E5A ×2
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×2
OUTDOOR MODEL U-71PE1E5A
Branch pipe MODEL CZ-P155BK1
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY
ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 220 230 240 Min Max
C
O
O
L
I
N
G
CAPACITY
kW 7.1 7.1 7.1 2.5 8.0
BTU/h 24200 24200 24200 8500 27300
CURRENT A 0.30 x 2 9.60 9.30 9.00 - -
INPUT POWER
W 40 x 2 1.985k 1.985k 1.985k - -
TOTAL W - 2.065k 2.065k 2.065k 450 2.650k
ANNUAL CONSUMPTION
TOTAL kWh
*
4 - - - - 1032.5 - - -
EER/EER CLASS
TOTAL(W/W)
*
5/("A"~"G")
- - - 3.44 3.44/A 3.44 5.56 3.02
Erp
*
6
Pdsign kW - - - - 7.1 -
SEER (W/W) - - - - 6.2 -
Annual consumption
kWh - - - - 401 -
Class - - - - A++ -
POWER FACTOR % - - - 94 93 92
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7
Power Level dB 51/47/41(46)*7
NOISE OUTDOOR
(H/L)
dB-A 48/-
Power Level dB 65/-
H
E
A
T
I
N
G
CAPACITY
kW 8.0 8.0 8.0 2.0 9.0
BTU/h 27300 27300 27300 6800 30700
CURRENT A 0.30 x 2 10.0 9.70 9.40 - -
INPUT POWER
W 35 x 2 2.080k 2.080k 2.080k - -
TOTAL W - 2.150k 2.150k 2.150k 400 2.900k
COP/COP CLASS
TOTAL(W/W)
*
5/("A"~"G")
- - - 3.72 3.72/A 3.72 5.00 3.10
Erp
*
6
Pdsign kW - - - - 7.1 -
Tbivalen °C - - - - -7 -
SCOP (W/W) - - - - 3.8 -
Annual consumption
kWh - - - - 2616 -
Class - - - - A -
POWER FACTOR % - - - 95 93 92
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7 -
Power Level dB 51/47/41(46)*7 -
NOISE OUTDOOR
(H/L)
dB-A - 50/-
Power Level dB - 67/-
EXTRA LOW TEMP
Total CAPACITY(kW)/INPUT POWER(W)/COP
-
MAX CURRENT(A)/MAX INPUT POWER(W) 0.35/50 x 2 18.0/3.80k 18.0/3.93k 18.0/4.06k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 10.0/2.0k 9.70/2.0k 9.40/2.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 x 2 90
MOISTURE REMOVAL VOLUME L/h(Pt/h) 4.2 (2.1×2) (8.8) -
I/D AIR
FLOW
COOL m
3
/min (ft
3
/min)
9.7×2/8.0×2/6.0×2*7 (343)×2/(283)×2/(212)×2
HEAT m
3
/min (ft
3
/min)
9.9×2/8.2×2/6.0×2*7 (350)×2/(290)×2/(212)×2
O/D AIR
FLOW
COOL m
3
/min (ft
3
/min) 60 (2119)
HEAT m
3
/min (ft
3
/min) 60 (2119)
REFRIGERANT TYPE, AMOUNT
g
(oz) R410A 2.35k (82.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 996 (39-7/32)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625
-
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1136
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) k
g
(lb) 18 (40) 69 (152)
(GROSS) k
g
(lb) 23 (51) 77 (170)
Panel : (NET) k
g
(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11 (12) 2 (3)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch)
(Liquid)ø6.35(1/4) (Gas)ø12.7(1/2)
(Liquid)
ø
9.52(3/8) (Gas)
ø
15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft)
ared type, 5.0 (16.4) ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft)
5 ~ 50 (16.4 ~ 164.0)
I/D&O/D HEIGHT DIFFERENCE m (ft)
15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft)
50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft)
30 (98.4)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m
3
/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7
°C
dry bulb and -8
°C
wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
*7: Noise and air flow rate of L are indicated by the values at FAN mode. ( ):Normal operation Cooling/Heating noise value. Normal operation Cooling/Heating air flow rate are
7.6 (m
3
/min).
SM830231-02Single.indb128SM830231-02Single欧州.indb128 2014/09/1913:21:082014/09/1913:21:08
