Simultaneous (Double-Twin) -Type

1-1. Unit Speciﬁ cations

PE1

6. 4-Way Cassette 60×60 Type S-36PY2E5A×4 / U-125PE1E5A

INDOOR MODEL S-36PY2E5A ×4

PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×4

OUTDOOR MODEL U-125PE1E5A

Branch pipe MODEL CZ-P155BK1

PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102

POWER SUPPLY

ø, Hz 1ø 50Hz 1ø 50Hz

V 220 230 240 220 230 240 Min Max

CAPACITY

kW 12.5 12.5 12.5 3.3 14.0

BTU/h 42700 42700 42700 11300 47800

CURRENT A 0.30 × 4 17.5 16.9 16.4 - -

INPUT POWER

W 40 × 4 3.680k 3.680k 3.680k - -

TOTAL W - 3.840k 3.840k 3.840k 840 4.600k

ANNUAL CONSUMPTION

TOTAL kWh

4 - - - - 1920 - - -

EER/EER CLASS

TOTAL(W/W)

5/("A"~"G")

- - - 3.26 3.26/A 3.26 3.93 3.04

Erp

Pdsign kW - - - - - -

SEER (W/W) - - - - - -

Annual consumption

kWh------

Class - - - - - -

POWER FACTOR % - - - 96 95 93

NOISE INDOOR

(H/M/L)

dB-A 36/32/26(31)*7

Power Level dB 51/47/41(46)*7

NOISE OUTDOOR

(H/L)

dB-A 53/-

Power Level dB 70/-

CAPACITY

kW 14.0 14.0 14.0 4.1 16.0

BTU/h 47800 47800 47800 14000 54600

CURRENT A 0.30 × 4 17.9 17.3 16.8 - -

INPUT POWER

W 35 × 4 3.750k 3.750k 3.750k - -

TOTAL W - 3.890k 3.890k 3.890k 900 5.200k

COP/COP CLASS

TOTAL(W/W)

5/("A"~"G")

- - - 3.60 3.60/A 3.60 4.56 3.08

Erp

Pdsign kW - - - - - -

Tbivalen °C - - - - - -

SCOP (W/W) - - - - - -

Annual consumption

kWh------

Class - - - - - -

POWER FACTOR % - - - 95 94 93

NOISE INDOOR

(H/M/L)

dB-A 36/32/26(31)*7 -

Power Level dB 51/47/41(46)*7 -

NOISE OUTDOOR

(H/L)

dB-A - 53/-

Power Level dB - 70/-

EXTRA LOW TEMP

Total CAPACITY(kW)/INPUT POWER(W)/COP

MAX CURRENT(A)/MAX INPUT POWER(W) 0.35/50 × 4 28.0/6.00k 28.0/6.20k 28.0/6.40k

STARTING CURRENT(A)/COMP OUTPUT(W) - - - 17.9/3.0k 17.3/3.0k 16.8/3.0k

NETWORK IMPEDANCE (ΩMAX.) - -

FM OUTPUT (W) 40 × 4 90 × 2

MOISTURE REMOVAL VOLUME L/h(Pt/h) 7.9 (1.975×4) (16.6) -

I/D AIR

FLOW

COOL m

/min (ft

/min)

9.7×4/8.0×4/6.0×4*7 (343)×4/(283)×4/(212)×4

HEAT m

/min (ft

/min)

9.9×4/8.2×4/6.0×4*7 (350)×4/(290)×4/(212)×4

O/D AIR

FLOW

COOL m

/min (ft

/min) 130 (4591)

HEAT m

/min (ft

/min) 110 (3885)

REFRIGERANT TYPE, AMOUNT

(oz) R410A 3.40k (119.9)

HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 1416 (55-3/4)

WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)

DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)

Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625

HEIGHT : H mm 345 (13-19/32) 1556

WIDTH : W mm 691 (27-7/32) 1055

DEPTH : D mm 691 (27-7/32) 485

MASS

(NET) k

(lb) 18 (40) 98 (216)

(GROSS) k

(lb) 23 (51) 108 (238)

Panel : (NET) k

(lb) 2.4 (5.3) -

LAYERS LIMIT (actually) 11 (12) 1(2)

Operation

Condition

Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C

Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C

PIPE DIAMETER mm (inch)

(Liquid)ø6.35(1/4) (Gas)ø12.7(1/2)

(Liquid)

9.52(3/8) (Gas)

15.88(5/8)

CONNECT METHOD, STD LENGTH m (ft)

ﬂ ared type, 5.0 (16.4) ﬂ ared type, 5.0 (16.4)

PIPE LENGTH RANGE m (ft)

5 ~ 75 (16.4 ~ 246.1)

I/D&O/D HEIGHT DIFFERENCE m (ft)

15(OD located lower)/30(OD located higher) (49.2/98.4)

ADD GAS AMOUNT

/m (oz/ft)

50 (0.538)

PIPE LENGTH FOR ADDITIONAL GAS m (ft)

20 (65.6)
