Panasonic CZ-KPY3A series Technical Data & Service Manual

1
1-426
Outdoor air intake temp(°C D.B.)
Model
Power
Source
Ambient
Return
Air
25°C 30°C 35°C 40°C 46°C
DB WB TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
S-50PY2E5A×3
U-140PE1E5A
(U-140PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
23
16 14.1 10.4 4.87 14.1 10.5 5.23 13.6 10.3 5.56 12.6 9.8 5.79 9.2 8.3 4.73
19 15.1 8.0 5.08 15.1 8.1 5.46 14.5 7.8 5.80 13.5 7.4 6.04 9.8 5.9 4.93
22 16.5 5.6 5.25 16.5 5.6 5.64 15.9 5.4 6.00 14.8 5.0 6.25 10.8 3.7 5.10
25
16 14.6 12.4 4.95 14.6 12.4 5.32 14.0 12.0 5.66 13.1 11.8 5.88 9.5 9.5 4.81
19 15.6 9.8 5.16 15.6 9.9 5.55 15.0 9.5 5.90 13.9 9.2 6.14 10.2 7.6 5.02
22 17.1 7.4 5.34 17.1 7.5 5.74 16.4 7.1 6.11 15.3 6.8 6.35 11.2 5.3 5.19
27
16 15.1 14.3 5.03 15.1 14.4 5.41 14.5 14.0 5.75 13.5 13.5 5.98 9.9 9.9 4.89
19 16.1 11.8 5.25 16.1 11.8 5.64 15.5 11.4 6.00 14.4 11.2 6.24 10.5 9.4 5.10
22 17.7 9.3 5.43 17.7 9.4 5.83 17.0 9.0 6.21 15.8 8.7 6.46 11.5 7.0 5.28
29
16 15.3 15.3 5.05 15.3 15.3 5.42 14.7 14.7 5.77 13.7 13.7 6.00 10.0 10.0 4.90
19 16.4 13.6 5.26 16.4 13.6 5.65 15.7 13.2 6.01 14.6 13.0 6.26 10.7 10.7 5.11
22 17.9 11.1 5.44 17.9 11.2 5.85 17.2 10.8 6.22 16.0 10.5 6.47 11.7 8.7 5.29
32
16 15.5 15.5 5.06 15.5 15.5 5.43 14.9 14.9 5.78 13.9 13.9 6.01 10.2 10.2 4.91
19 16.6 13.8 5.28 16.6 13.8 5.67 16.0 13.5 6.03 14.8 13.2 6.27 10.9 10.9 5.13
22 18.2 11.3 5.46 18.2 11.4 5.86 17.5 11.0 6.24 16.3 10.7 6.49 11.9 8.9 5.30
1-13. Capacity Table
1. Cooling Capacity Performance Data
•
Combination of Multiple Unit
4-Way Cassette 60×60 Type
TC :Cooling Capacity
SHC :Sensible Heat Capacity
IPT :Cooling Power Consumption
unit : kW
