Panasonic CZ-KPY3A series Technical Data & Service Manual

1
1-452
1-13. Capacity Table
2. Heating Capacity Performance Data
•
Combination of Multiple Unit
4-Way Cassette 60×60 Type
TC :Cooling Capacity
IPT :Cooling Power Consumption
unit : kW
Outdoor air intake temp(°C W.B.)
Model
Power
Source
Ambient
Return
Air
-5°C 0°C 6°C 10°C 15°C
DB TC IPT TC IPT TC IPT TC IPT TC IPT
S-36PY2E5A×2
U-71PE1E5
(U-71PE1E8)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 8.2 2.88 8.5 2.90 9.7 2.86 9.9 2.67 9.9 2.47
20 7.8 2.96 8.1 2.98 9.0 2.90 9.0 2.72 9.0 2.49
24 7.4 3.05 7.7 3.07 8.1 2.96 8.1 2.78 8.1 2.55
S-36PY2E5A×3
U-100PE1E5
(U-100PE1E8)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 15.1 4.97 15.1 4.77 15.1 4.16 15.1 3.66 15.1 3.10
20 14.0 5.26 14.0 5.05 14.0 4.40 14.0 3.87 14.0 3.28
24 13.1 5.34 13.1 5.13 13.1 4.47 13.1 3.94 13.1 3.33
S-50PY2E5A×2
U-100PE1E5
(U-100PE1E8)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 15.1 4.97 15.1 4.77 15.1 4.16 15.1 3.66 15.1 3.10
20 14.0 5.26 14.0 5.05 14.0 4.40 14.0 3.87 14.0 3.28
24 13.1 5.34 13.1 5.13 13.1 4.47 13.1 3.94 13.1 3.33
S-36PY2E5A×4
U-125PE1E5
(U-125PE1E8)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 16.7 5.52 17.2 5.43 17.3 4.91 17.3 4.33 17.3 3.66
20 15.5 5.84 15.9 5.74 16.0 5.20 16.0 4.58 16.0 3.87
24 14.5 5.93 14.9 5.84 15.0 5.28 15.0 4.65 15.0 3.94
S-45PY2E5A×3
U-125PE1E5
(U-125PE1E8)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 16.7 5.52 17.2 5.43 17.3 4.91 17.3 4.33 17.3 3.66
20 15.5 5.84 15.9 5.74 16.0 5.20 16.0 4.58 16.0 3.87
24 14.5 5.93 14.9 5.84 15.0 5.28 15.0 4.65 15.0 3.94
S-50PY2E5A×3
U-140PE1E5
(U-140PE1E8)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 18.1 5.72 19.2 5.69 19.4 5.57 19.4 4.91 19.4 4.15
20 16.7 6.05 17.8 6.02 18.0 5.90 18.0 5.19 18.0 4.40
24 15.7 6.15 16.7 6.12 16.9 6.00 16.9 5.28 16.9 4.47
