Page #3 background imageLoading...
Page #3 background image
3-36
Control of 2WAY SYSTEM
1
2
3
4
5
6
7
8
9
3. Timer Remote Controller
Names and Operations
1. (Start/Stop) button
Pushing this button starts, and pushing again stops the
unit.
2. Operation lamp
The lamp is turned on when an air conditioner is in opera-
tion.
This lamp blinks when an error occurs or a protective
device is activated.
3.
(Mode select) button
Pushing this button to select an operation mode. (AUTO
/HEAT /DRY /COOL /FAN ).
4. Temperature setting buttons
Changing the temperature setting.
5.
(Fan speed) button
Changing the fan speed.
6.
(Swing/Air direction) button *1
Use this button to set the auto swing or air direction to a
specifi c angle.
7.
(Unit select) button
When more than one indoor unit is operated by one re-
mote control unit, this button is used to select a unit when
adjusting the air direction.
8. Timer setting buttons
(
Weekly Program Function)
9.
(Filter reset) button
Use this button to reset the fi lter sign.
When is displayed, press this button after cleaning the
lter.
Operation Section (Refer to the previous page)
10.
(Ventilation) button
Use this button when you installed a fan available in the
market. Pressing this button turns on and off the fan.
When turning off the air conditioner, the fan will be also
turned off.
(While the fan is operating, will appear in the display.)
*If is shown on the display of the remote control unit
when the VENTILATION button is pressed, this indicates
that the ventilation fan is not connected.
11.
(Inspection) button
Do not use this button.
12.
(Sleeping) button
( Sleeping Function)
13. Remote control sensor
Normally, the temperature sensor of the indoor unit is
used to detect the temperature. However, it is also pos-
sible to detect the temperature around the remote control
unit.
*1 Do not move the fl ap (vertical airfl ow adjustment board)
with your hand.
The fl ap is automatically directed down when the unit is
stopped.
The fl ap is directed up during the HEAT standby. The
ap starts swinging after the HEAT standby is can-
celled, although the AUTO fl ap indication on the remote
control unit is displayed during the HEAT standby.
TD831151-002WAY.indb36TD831151-002WAY.indb36 2011/01/1317:07:522011/01/1317:07:52
