36
(EN)
Bluetooth® settingsBluetooth
®
settings
Flap setting for each air outlet (Lock individual ap)
When setting the ap for each air outlet individually according to the room condition
• Even if the ap setting of all indoor units or each indoor unit (P.35) is changed, the ap
directions set here are not changed.
• For types other than the 4-way cassette type, this screen does not
appear and this function cannot be used.
Select the air outlet
• The square mark (indented ) on the panel of the indoor unit
indicates air outlet No. 1. There are some models that do not have a
square mark (indented ).
• The air outlet No. changes according to the installation direction.
Check by actual operation.
Select the indoor unit
• 1-1→ 1-2 to 1-8 (MAX) → ALL
• ALL: All units connected to the remote contloller.
Auto air swing toggle
Change swing position
All the air outlets
1
2
3
4
To Next Page
