65
RQTV0141
Underlined items are the factory default settings.
Display
Status Messages
Choose whether to show status messages automatically or not.
[Automatic
] [Off]
On-screen Language
Choose the language for these menus and the on-screen
messages.
[English
] [Español] [Français]
Blue Background
Select whether to show the blue background, normally shown when
TV reception is poor.
[On
] [Off]
FL Display
Changes the brightness of the unit’s display.
[Bright
] [Dim] [Automatic]
TV Screen
TV Type (l 20)
Choose the setting to suit your TV and preference.
[Aspect 4:3 & 480i
] [Aspect 4:3 & 480p]
[Aspect 16:9 & 480i] [Aspect 16:9 & 480p]
Functions of HDMI
Press [ENTER] to show the following settings.
HDMI Video Output
[On] [Off]
HDMI Resolution
You can only select items compatible with the connected
equipment. This setting normally does not need to be changed.
However if you are concerned about output picture quality, it may
be improved by changing the setting.
[Auto
] [480p] [720p] [1080i]
HDMI Output Display Aspect
Settings used when 4:3 aspect video is output on the television as
16:9 aspect.
(Only effective when 720p or 1080i is selected as the output
resolution)
[Full] [Normal
]
HDMI RGB Output Range
Effective when connected to a device that only supports RGB
output.
[Standard
] [Enhanced]
HDMI Audio Output
[On] [Off]
HDMI Connection Speakers Setting
You can set the unit to output the best possible sound for your
speakers.
[Auto
] [Multi Channel] [2 Channel]
Multi Channel Setting
Displayed when “Multi Channel” is selected in “HDMI Connection
Speakers Setting”
You can adjust the settings for speaker size, presence and audio-
delay. (l 66)
Ctrl with HDMI
[On] [Off]
4:3 TV Settings for DVD-Video
You can select how to display the image on the TV when you watch
16:9 images (DVD-Video) on a 4:3 standard aspect TV. (l 76)
[Pan and Scan (Stretch to fit)
] [Letterbox (Shrink to fit)]
4:3 TV Settings for DVD-RAM
You can select how to display the image on the TV when you watch
16:9 images (DVD-RAM) on a 4:3 standard aspect TV. (l 76)
[4:3 Aspect] [Pan and Scan (Stretch to fit)]
[Letterbox (Shrink to fit)
]
VHS
Select Tape Length
Set the length of tape you are using so the unit can show the correct
remaining time.
[T120
] [T160] [T180]
Jet Search (l 37)
Set the speed for Jet Search when playing EP and VP tapes.
It is possible to view the picture recorded in EP or VP mode at
approx. 27 or 35 times speed.
[k27] [k
35]
Select [k27] if the picture is poor at [k35].
Automatic The display turns dark during play, and reappears
momentarily if a button is pressed. When the unit is
turned off, the unit’s display disappears. While using
this mode the standby power consumption can be
reduced.
Off Video is output from COMPONENT VIDEO OUT
terminal.
Auto
Automatically selects the output resolution best suited
to the connected television (
1080
i,
720
p or
480
p).
Full Video output is enlarged to match the screen size.
Normal Video is output as 4:3 aspect. Side panels (black bars
on the left and right) will appear on the screen.
Enhanced
When the black and white images are not distinct.
Off
Audio is output from an amplifier when using the
DIGITAL AUDIO OUTPUT terminal.
/
/
/
Auto When using the speaker settings of the connected
equipment
Multi
Channel
When using three or more speakers with equipment
that cannot set the speaker settings
2 Channel When using two speakers
On
Wh
en “On” is selected, you can operate other “Ctrl
with HDMI” compatible devices using the “Ctrl with
HDMI”.
Pan and Scan
(Stretch to fit)
Video recorded for a widescreen is played with
the sides cut off if Pan & Scan was specified.
If 16:9 software prohibits Pan & Scan, the
image will appear in the letterbox style (with
black bands above and below the picture)
despite the setting here.
Letterbox
(Shrink to fit)
Video recorded for a widescreen is played in
the letterbox style.
4:3 Aspect Titles are played as recorded.
Pan and Scan
(Stretch to fit)
Video recorded for a widescreen is played with
the sides cut off.
Letterbox
(Shrink to fit)
Video recorded for a widescreen is played in
the letterbox style.
T120 T30, T60, T90 and T120 tapes
T160 T140 and T160 tapes
T180 T180 tapes
Changing the unit’s settings
