Panasonic Diga DMR-XW390

Reference
VQT4C72
92
Specifications
Reference
Specifications are subject to change without
notice.
∫ General
Dimensions:
430 mm (W)
59 mm (H)
(excluding the projecting parts)
238 mm (D)
(including the projecting parts)
249 mm (D)
Mass:
Approx. 3.3 kg
Power supply: AC 220 to 240 V, 50 Hz
Power consumption: Approx. 30 W
“Power Save in Standby” is activated:
Approx. 1.1 W
“Power Save in Standby” is not activated:
Approx. 7 W
Operating temperature: 5 oC to 40 oC
Operating humidity range: 10 % to 80 % RH
(no condensation)
∫ TV system
Tuner System: DVB-T
Country: New Zealand
Channel Coverage: UHF 21~69
∫ Recording system
Video: MPEG-2 (Hybrid VBR),
MPEG-4 AVC/H.264
Audio:
Dolby Digital (XP, SP, LP, EP mode: 2ch)
LPCM (XP mode)
Dolby Digital
(DR mode, HG, HX, HE, HL, HM mode:
Max 5.1ch (DVB-T))
HE-AAC (DR mode: 2ch (DVB-T))
MPEG (DR mode: 2ch)
∫ Video
Video system: PAL/NTSC
Analog video in (pin jack): 1 pc.
Input level: 1 Vp-p (75 ≠)
Analog video out (pin jack): 1 pc.
Output level: 1 Vp-p (75 ≠)
∫ Audio
Analog audio L/R in (pin jack): 1 pc.
Input level:
Full scale 2.0 Vrms at 1 kHz (> 10 k≠)
Analog audio L/R out (pin jack): 1 pc.
Output level:
Full scale 2.0 Vrms at 1 kHz (< 1 k≠)
Digital audio out (optical): 1 pc.
Output format:
PCM, Dolby Digital, DTS, MPEG
∫ HDMI terminal
HDMI out (19 pin type A): 1 pc.
Output format:
PCM, Dolby Digital, DTS, MPEG
• This unit supports “HDAVI Control 5”
function.
∫ Internal HDD capacity
500 GB
∫ Other terminals
USB Port (Type A): 1 pc.
SD Card Slot: 1 pc.
LAN (Ethernet) Port: 1 pc.
10BASE-T/100BASE-TX
