59
Interface ports
RGB2 input terminal
Video input terminal
S-video input terminal
Serial input terminal
Remote1 input terminal
Remote2 terminal
DVI-D terminal
LAN terminal
Audio input terminal
Audio output terminal
1 set of high-density, D-sub 15p (female)
[For YPBPR input]
Y: 1.0 V [p-p] synchronization signal included, PBPR: 0.7 V[p-p] 75 Ω
[For RGB input] 0.7 V[p-p] 75 Ω For G-SYNC: 1.0 V[p-p] 75 Ω
HD/SYNC: TTL, high-impedance, positive/negative polarity
automatically adjusted
VD:
TTL, high-impedance, positive/negative polarity automatically adjusted
• However, HD/SYNC, and VD terminals are not compliant with 3-value
direct SYNC.
1 set RCA
1.0 V[p-p] 75 Ω
1 set Mini DIN 4p
Y 1.0 V[p-p] C 0.286 V[p-p] 75 Ω Compliant with S1 signals
D-sub 9-pin (female), RS232C compliant
Used for personal computer control
1 set for M3 stereo mini jack
Wired remote control
D-sub 9-pin (female)
Used for external control
DVI-D 24-pin
RJ-45 Compliant with PJLink™
1 set of M3 stereo mini jacks (L and R) for RGB1/RGB2/DVI input
1 set of RCA (L and R) for Video/ S-Video input
1 set of M3 stereo mini jacks (L and R)
Length of power supply cord 3.0 m (9.1')
Cabinet Molded resin
Outside dimensions Width: 332 mm (13.1"); Height : 168 mm (6.6"); Depth: 425 mm (16.7")
Mass
7.9 k (17.4 lb)
Working environment condition
3
Ambient temperature: 0 °C to 40 °C
Ambient humidity: 20 % to 80 % (no condensation)
Remote control
Power source
Operation range
Mass
Outside dimensions
3 V DC (two AAA dry cells)
approx. 7 m (22' 11") (in front of beam receiver)
95 (0.21 lb) (including dry cells)
Width: 45 mm (1.8"), Thickness: 23 mm (0.9"), Depth: 145 mm (5.7")
Option
Hanging attachment (For high ceiling) : ET-PKD35
Hanging attachment (For low ceiling) : ET-PKD35S
Projection lens : ET-DLE100, ET-DLE200, ET-DLE300, ET-DLE400, ET-DLE050
Wireless mouse receiver : ET-RMRC2
Replacement lamp unit : ET-LAD35 (single bulb)
Long life lamp unit : ET-LAD35L (single bulb)
• The outside dimensions do not include the lens and other protruding parts. See page 63 for further details.
3
When using the projector at high altitudes (1 400 to 2 700 m) (4 605.3' to 8 881.5'), the upper limit for the
ambient temperature drops by 5 °C.
